Installation Instructions
SKU 200290/200291 Date: 2015-12-14 Version 1.0
8. Replace the LED connector and then secure the fascia into the fan body via the 2 springs.
9. Switch on Exhaust fan and LED light to check and use.
Maintenance
 Always ensure the power is switched OFF and the lamp has cooled down before performing any maintenance
and cleaning.
 LED Light source cannot be replaced.
 Ensure that the fitting does not come in contact with corrosive chemicals, etc.
 To clean, wipe with a warm soapy damp clean cloth. Never soak the fitting with water.
Specifications
SKU #
200280 (White)
200281 (Silver)
Rated Voltage
220-240V AC
Fan Rated
Wattage
30 Watts
Light Globe
Wattage
Max. 12W LED TYPE
(not replaceable)
Cutout Size
230mm Diameter
Duct Fan
Outlet
100mm Diameter
IP Rating
IP20 (ordinary)
Dimensions
270mm X 270mm X 175mm (L X W X H)
Weight
1.6 Kg (With Fascia)
