363-205-401 Power Up: DLP-513
Issue 7, March 1997 Page 5 of 8
20.
!
DANGER:
High current flow will occur if short is placed across battery terminals. No
attempt should be made to measure battery voltage across terminals.
Get four KS-21906, L4 battery packs.
21. Remove fuses, if present, from
+BAT
and −
BAT
fuse holders on battery shelf.
22. At front of battery shelf, remove front cover by lifting cover up and out (Figure
2).
23. Place batteries on battery shelf and dress battery cables as each battery pack
is placed on shelf (Figure 3).
24.
NOTE:
Four battery jacks can be plugged into any four plugs on shelf, in any
order.
Connect four battery lead jacks to four plugs (
P1
,
P2
,
P3
, and
P4
) on top of
battery shelf.
25. Reinstall front cover on battery shelf.
26. Condition DMM to measure DC volts.
27. On battery shelf, connect DMM test leads to
+BAT
jack (
J5
) and −
BAT
jack
(
J6
).
To Next Page
