Power Up: DLP-514 363-205-401
Page 2 of 4 Issue 7, March 1997
Figure 1 – Location of Fuses on 337A BATTERY CHARGER
HIGH
RATE
CHG
ACTIVATE
BAT DISCHG
CHARGER
BATTERY
OPEN BATT
ON
337A
FUSES
Lucent
