Lucent Technologies SLC 5 Series - Page 202

363-205-401 Power Up: DLP-527
Issue 7, March 1997 Page 3 of 6
Figure 2 – ED-7C704-30 Rectifier Shelf (With Cover)
RECTIFIER 3
ED7C704-30
OLS RECTIFIER SHELF
RECTIFIER 1 RECTIFIER 2
(SLIDE DOWN TO RELEASE)
COVER LATCHES
