RT Turn Up: DLP-506 363-205-401
Page 4 of 8 Issue 7, March 1997
!
CAUTION:
FPB Mode 2 must be set to NC for ADU FAIL, MN, NE, and CMP alarms
to clear.
4 -
Toward
DBL
.
5 -
Toward
NPA
.
6 -
Toward
MNP
.
7 and 8 -
Unused.
6. Set switch
S3
toward
DL
.
7. Set system identification rotary switches
S4
(most significant digit) through
S7
(least significant digit) to bank ID number.
8. Set rotary switches
S8
through
S11
to
0
.
9.
NOTE:
The
NORM/CLEAR
switch option is used to automatically clear random
channel provisioning data stored in the
ADU
and
BCU
when the
BCU
is
installed by selecting
CLEAR
. After the
BCU
has been installed, the
NORM
position is used.
Set
NORM/CLEAR
option plug for
CLEAR
option (center and bottom pins).
10.
!
CAUTION:
Incorrectly set ADU option switches may result in immediate or future
loss of service or may introduce errors into the digital bitstream.
Insert
ADU
into lower
ADU
slot if equipping blue bank or upper
ADU
slot if
equipping white bank.
Response: Disregard all indicators that may be lighted.
11.
NOTE:
When the BCU is first installed, the ADU should be set for preservice and
unequipped digroups (AB and CD) to verify these units (ADU and BCU)
are functioning properly (all alarms clear).
Install BCU.
Reference: DLP-508
