Acceptance: DLP-501 363-205-401
Page 2 of 4 Issue 7, March 1997
13.
NOTE:
Plug-in units are not inserted into connectors until all tests and
verifications have been completed.
At both white and blue banks, insert channel unit in slots labeled
1/2
,
23/24
,
and
47/48
on shelf AB and slots
49/50
,
71/72
, and
95/96
on shelf CD to check
for misaligned or bowed shelves. Remove unit and proceed to Step
14.
14. Inspect for misaligned, dented, or twisted shelves.
15. Are there any misaligned, dented, or twisted shelves?
If
YES,
then continue with Step
15.
If
NO,
then proceed to Step
16.
16. Resolve problems through local procedures.
17. Verify that 3-type protectors are installed in protector panel.
18. Use special key to open electronics section of cabinet (separate electronics
section of cabinet from battery section of cabinet).
19. Verify that power and battery shelves are properly installed and tightly
secured.
20. At front of battery section of cabinet, verify that battery shelves are free from
defects (are not dented or twisted).
21. At rear of electronics section of cabinet, perform Steps
21
through
24
.
22. Verify that there is no broken or damaged equipment (connectors, wiring,
backplane wiring board, etc). Resolve problems through local procedures.
23. Verify that there are no bent, broken, or crossed terminals on backplane.
Resolve problems through local procedures.
24. Verify that all cabling and wiring are terminated and tied into forms. Resolve
problems through local procedures.
25. Verify that plastic covers are placed behind dual bank assembly and power
shelf. Resolve problems through local procedures.
