Lucent Technologies SLC 5 Series - Page 37

Acceptance: DLP-502 363-205-401
Page 2 of 4 Issue 7, March 1997
Figure 1 –
LGX
Lightguide Distribution Frame Ground
Top Raceway
Assembly
(Part of Network
Bay Frame)
Bay Frame
Frame Aisle
Network
Ground Lead
Lug Terminal
Ground Wire
