Acceptance: DLP-505 363-205-401
Page 2 of 6 Issue 7, March 1997
Figure 2 – Low Profile Pedestal Equipment Arrangement
3. Verify that the pedestal ground bus has been connected to an approved
ground connection. (Figure 3)
Pass-Through
Case
Splice
Protectors
Power Box &
2500
DT1
DT2
DT3
For Cables
