Power Up: Introduction-000 363-205-401
Page 6 of 8 Issue 7, March 1997
ED7C704-30 OLS Rectifier Shelf
This power shelf is used in 80E or 80D bulk power cabinets, along with the
J1C182BC ring shelf (non-FTTH) and a central interconnect panel.
Figure 5 – ED-7C704-30 Rectifier Shelf (With Cover)
The ED7C704-30 OLS (Figure 5) requires the following equipment:
•2 or 3
Chloride
*
or Lineage VR Series Battery strings at the bottom of the cabinet
mounted on heaters.
• 2 or 3 CS787B540 power units.
*. Registered trademark of Chloride Group, Plc.
RECTIFIER 3
ED7C704-30
OLS RECTIFIER SHELF
RECTIFIER 1 RECTIFIER 2
(SLIDE DOWN TO RELEASE)
COVER LATCHES
