363-205-401 Power Up: NTP-007
Issue 7, March 1997 Page 3 of 4
DO ITEMS BELOW IN ORDER LISTED FOR DETAILS, GO TO
4.
NOTE:
Batteries are shipped directly from manufacturer.
Install and test RT batteries in 80D or 80E cabinet skirt:
DLP-524A.
Chloride
batteries in 80E cabinet.
DLP-525B. Lineage 2000 VR Series batteries in 80E cabinet.
DLP-534C. Lineage 2000 VR Series batteries in 80D cabinet.
DLP-535D.
Chloride
batteries in 80D cabinet.
DLP-5265. Verify connections to ED-83114-30 control & distribution panel.
DLP-5276. Install power units in rectifier shelf.
DLP-5287. Install
3C RINGING GENERATOR
s in ring shelf. (Not required for
FTTH arrangement)
DLP-5298. Install
RCU
(ring control unit) in ring shelf. (Not required for FTTH
arrangement)
9.
NOTE:
Each circuit breaker on control and distribution panel
supplies an equipment bay according to the cabinet group
arrangement. To identify circuit breakers, refer to the label
located on the door opposite the Control and Distribution
Panel.
Turn on one circuit breaker and verify the it does not trip. If the cir-
cuit breaker does trip, cabinet wiring trouble must be cleared
before continuing.
10. If the circuit breaker powers RT dual channel bank(s) or
J1C182PB-1 Optics Power shelf, continue with step
11
. Other-
wise, proceed to Step
12
.
