363-205-401 Power Up: DLP-504
Issue 7, March 1997 Page 3 of 6
6. Batteries are on high charge and may require up to 24 hours to charge. Do not
perform this procedure until
HIGH RATE CHG/ON
indicator on
BATTERY
CHARGER
goes off.
7.
!
CAUTION:
Service interruption will occur if batteries are disconnected and AC power
is not available.
Disconnect battery leads of batteries to be tested from battery shelf.
8.
NOTE:
Under normal conditions, when the first battery is connected, the
following occurs: (a) The test set
TIME
display indicates
00 MIN:00 SEC
;
(b) The status display indicates which test set
BATT
plug the battery is
connected to, status of the battery (
GOOD
or
REPLACE
), and the
READY
indicator lights; (c) Test set fan operates.
At test set connector head (Figure 1), connect battery leads (up to four) to
BATT 1, 2, 3,
and
4
plugs.
9.
NOTE:
If status display does not indicate battery number of battery status,
BATT
fuse may be blown, connector head or test set may be defective, or
battery pack may be defective.
Does test set display indicate
REPLACE
for all batteries being tested?
If
YES,
then continue with Step
10.
If
NO,
then proceed to Step
12.
10. Replace all batteries and connect good batteries to battery shelf.
11. Place batteries on high charge by depressing
HIGH RATE CHG/ACTIVATE
pushbutton on
BATTERY CHARGER
and repeat from Step
6.
