Lufft WS600-UBM - Page 111

Operating Instructions Smart Weather Sensor
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 111
19.6.5.7 Buffer Assignment Additional Measurement Commands M7 / C7: Global
Radiation
Device configured for measurement values in metric units:
Measurement Value
UMB
Channel
Min
Max
Unit
Buffer ‘0’
Global Radiation (act)
900
0.0
2000.0 *)
W/m²
Global Radiation (min)
920
0.0
2000.0 *)
W/m²
Global Radiation (max)
940
0.0
2000.0 *)
W/m²
Global Radiation (avg)
960
0.0
2000.0 *)
W/m²
Buffer ‘1’ (WS800-UMB only)
Lightning Events (minute)
617
0
255
-
Lightning Events (Intervall)
677
0
999
-
reserved
reserved
reserved
Buffer ‘2’ (WS800-UMB only)
reserved
*) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m
2
Example: Request with M Command
0M7!
00004<CR><LF>
0D0!
0+780.0+135.0+920.0+530.0<CR><LF>
Device configured for measurement values in US units:
Measurement Value
UMB
Channel
Min
Max
Unit
Buffer ‘0’
Global Radiation (act)
900
0.0
2000.0 *)
W/m²
Global Radiation (min)
920
0.0
2000.0 *)
W/m²
Global Radiation (max)
940
0.0
2000.0 *)
W/m²
Global Radiation (avg)
960
0.0
2000.0 *)
W/m²
Buffer ‘1’ (WS800-UMB only)
Lightning Events (minute)
617
0
255
-
Lightning Events (Intervall)
677
0
999
-
reserved
reserved
reserved
Buffer ‘2’ (WS800-UMB only)
reserved
*) Until device version .49 / .212 / Firmware v5.6: 1400.0 W/m
2
