Operating Manual Smart Weather Sensor
22 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany
Figure 2: Fastening to
the Mast
7 Installation
The sensor bracket is designed to be installed on the top of a mast with a diameter of 60 –
76mm.
The following tools are required for the installation:
 Open-end or ring spanner (SW13)
 Compass for aligning the wind meter to the North
7.1 Fastening
 Loosen nuts
 Push the sensor onto the top of the mast from above
 Tighten the nuts evenly until contact is made with the springs but the sensor can still be
moved easily
 Align the sensor to the North (for wind meters)
 Tighten both nuts with 3 revolutions
Mast tube
Mounting bracket
Springs
Nuts with washers
