Lufft WS600-UBM User Manual

Operating Instructions Smart Weather Sensor
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 127
Smart Weather Sensor Type Code
WS200-UMB
2
WS304-UMB
43
WS300-UMB
3
WS310-UMB
93
WS400-UMB
4
WS501-UMB
15
WS500-UMB
5
WS502-UMB
25
WS600-UMB
6
WS503-UMB
35
WS700-UMB
7
WS504-UMB
45
WS800-UMB
8
WS510-UMB
95
WS301-UMB
13
WS401-UMB
14
WS302-UMB
23
WS601-UMB
16
WS303-UMB
33
Sensor Status:
Each register hoIds 4 sensor status coded with 4 bits per status, so that together they build
one 16bit number. The sequence defined in the table above is to understand as from most
significant half byte to least significant half byte. Most of the sensors have two status values,
one for the sensor itself and the current measurement value, another one for the buffer, from
which average, min. And max values are evaluated.
Assignment of Status Information to Status Register
Register
Byte
Half-
Byte
Status
Sensor Status 1
High
High
Temperature Buffer
Low
Temperature
Low
High
Dewpoint Buffer
Low
Dewpoint
Sensor Status 2
High
High
Rel. Humidity Buffer
Low
Rel. Humidity
Low
High
Abs. Humidity Buffer
Low
Abs. Humidity
Sensor Status 3
High
High
Mixing Ratio Buffer
Low
Mixing Ratio
Low
High
Air Pressure Buffer
Low
Air Pressure
Sensor Status 4
High
High
Wind Buffer
Low
Wind
Low
High
Precipitation
Low
Compass
Sensor Status 5
High
High
Global Radiation Buffer
Low
Global Radiation
Low
High
Leaf Wetness Buffer
Low
Leaf Wetness
Sensor Status 6
High
High
Low
External Temperature
Low
High
Lightning Sensor Buffer
Low
Lightning Sensor
