LR510
LR510 Specifications
Self-levelling range ± 3.5° (horizontal)
Accuracy ± 3mm / 10m
Vertical levelling manual
Perpendicular reference beam 90° to rotation plane
Rotation speed 100 - 300 rpm
Laser wavelength 635 nm
Laser Class IIIA (EN60825-1:2007-10)
Laser output rating ≤ 5 mW
Rechargeable Batt. / batt. operating time approx. 20 h / 45 h, 4 x type AA
Battery recharging time approx. 14 h
Working temperature range -10°C - +40°C
Protection class IP 54
Weight 1.65 kg
Laser Receiver
Batteries / Power supply 4 x type AA
Battery life approx. 70 h
Laser reception range:
SensoLite 210
200m
Operating temperature 0°... 50°C
Storage temperature -10°C ... 70°C
Technical Specifications
