Luiton LT-198 - Page 4

6
6. Specication
Dimensions 102 x 100 x 25 mm³
Weight 450 gr
Supply Voltage 13,2 V
Current Consumption 2 A max
Operating Temperature Range -20 to +50°C
Antenna Socket UHF, SO-239
Frequency Error < +/- 300 Hz
TX Power 4 Watt
Spurious Transmissions < 4 nW (-54 dBm)
Adjacent Channel Power < 20 μW
FM Deviation 1.9 kHz
AM Modulation Index 85-90%
RX Sensitivity better than 1 μV
Image Rejection 70dB
Adjacent Channel Rejection 60dB
Audio Output 1 Watt into 8 Ohm
Frequency Response 300-3000Hz
