TECHNICAL CHARACTERISTICS
GENERAL
Modulation modes AM/FM
Frequency ranges 26.965---27.405MHz
Antenna impedance 50 Ohms
Power supply 13.2V
Dimensions(in mm) 150×140×41mm
Weight 761G
TRANSMISSION
Frepuency error +/- 300HZ
Carrier power 1W/4W
Transmission interference inferior to 4nW(-54dBm)
Audio response 300HZ to 3KHZ in AM/FM
Emitted power in the adj.channel inferior to 20uW
Microphone sensitivity 3mV
Maximum current max 3A
Modulated singal distortion inferior to 5%
RECEPTION
Max sensitivity at 20dB sinad
0.8uV -113 dBm FM
1.5uV -103 dBm AM
Frequency response 300HZ to 3KHZ in AM/FM
Adjacent channel selectivity 60dB
Maximum audio power 3W
Squelch sensitivity
Minimum 0.2uv -120 dBm
Maximum 1mV -47 dBm
Maximum current 0.3A nominal/1.2A maximum
