20
BACKGROUND Screen
:
Inputs 1/2/3/4
CHROMA/LUMA
Chroma
:
Used a lot in programs like weather broadcast
Luma
:
Used to apply power point screens
LOGO1 & LOGO2
File formats in bmp and png can be applied through USB 2.0
Saved in the internal ROM.
Max size
:
512 x 512 up to 2 logos
PICTURE IN PICTURE (PIP)
Inserts a screen over another screen
1
2
3 3
4
X and Y Coordinates (0,0) for PIP / LOGO1/ LOGO2
X and Y Coordinates (1920,1080) or (1280,720) for PIP/LOGO1/LOGO2
5. Screen
Program Screen
