22
4x1 Video Switcher with Scaler
Input
Video Input: SDI(BNC 75Ω) x2, HDMI x3
Analog Audio Input : 6.35mm(1/4") Phone Jack(Balanced) x 2
±10V (Max) @ -10dB
Output
Video Output(PGM) HDMI x1, SDI(BNC 75Ω)x1
Multiview Output: HDMI x1
Analog Audio Output: 3.5mm Stereo Jack x 1
Key
- PIP x 1
- LOGO x 2
- CHROMA/LUMA x 1
Internal Processing : 4:2:2 10bits/8bits
Resolution supported
Input
- SD : 480i59/ 576i50/
- HD : 1080p30/1080p29/1080p25/1080p24/1080p23/
1080i60/1080i59/1080i50/720p60/720p59/720p50
- Full HD : 1080p60/1080p59/1080p50
Output
- HD : 1080p30/1080p29/1080p25/1080p24/1080p23/
1080i60/1080i59/1080i50/720p60/720p59/720p50
- Full HD : 1080p60/1080p59/1080p50
Management
Console
USB2.0 @ GUI application, Firmware Upgrade, LOGO Update
Physical
Dimension : 70(H) X 297(W) X 230(D)(excluding connectors)
Power Input: DC 7 - 14V
Operation Temperature: 0 - 40C
Power Consumption: 20W(max)
Weight: 1.7Kg
6. System Specification
