• Donotremovethetoolfromtheloguntilthedrillcomestoa
completestop.Failuretodosowillwafflecutthetenonorcause
harmtotheoperator.Donotplacehandsorbodypartsnearthe
toolorbladeswhileinoperation

• Donotdroporallowthetooltofalltothefloorbyitselforwhilein
thedrill.Doingsomaybendtheshankordamagethetool.This
damageisnotcoveredbythewarranty

Maintenance

Itisbestifyoukeepthetenoncutterbodycleanofsapandbuildup.
Removethebladesfromthetoolfirst.Carefullycleanthetoolwiththe
solventorcleanerofyourchoice,anddrywhencompleted.

Thebladesaremadefromhighqualitytoolsteel,andmayformoxidation.
Thisisanaturaloccurrenceandwillvarydependingonyourgeographic
location,climateandshopenvironment.Youshouldperiodicallycleanthe
bladesandapplyathinfilmofoil.

Resharpeningtheblades:Wearsafetyglasses,andusecautionwhen
sharpeningtheblades.Everytimeyouresharpentheblades,youmust
applyathinfilmofoil.Useextremecautionsonottocutyourself.

WerecommendourBladeBossJig0750(BB0750)forsharpeningtheblades.
(BB0750NotIncluded)

Shank:Oneoftheuniquefeaturesaboutourtenoncuttersisthattheyoffer
areplaceableshank.Intherareinstancethatyourshankbreaks,weoffer
replacementshanksforsalesoyoudon’thavetoreplacetheentiretenon
cutter.Theshanksarethreaded,sotoloosenthem,turntheshanktothe
left

UsingtheInSightMeasurementSystem


QuickStopPins
Includedinthefollowingkits:PSK2,PSK3,PSK5
(Alsoavailableforindividualpurchase)

OurQuickStopPinsfitintothe1”,1½”and2”ProSeriesTenonCutters.
Thesepinsstopthelogatthespecifiedtenonlengthtoavoidmeasurement
basedonsightalone.






2.5”fromthe
faceofthetenon
tooltothefirst
Radial
Measurement
Ring.(Models:
TTR0750
TTR2000)
Models:TTR0500
&TTR0625(2”)
Radial
Measurement
Ringsevery½”
4InSight
measurement
slotsevery90°for
easeofsight.
TheQuickStop
Pinsstopthelog
atthedesired
length.
Viewofthepin
insidethemouth
ofthetenon
