Lumberjack Log Lock - Operating the Log Lock; Adjusting Ladder Settings

During work if you notice the log start to wobble or looks like it may spin
loose your current actions.
● Make sure the fixture is tight on the log
● Reposition the log so that it is more stable
● Try readjusting the ladder to better fit the log
● Avoid clamping on knots and uneven points on log
7
Using the Log Lock
● Some logs will be
twisted and knotty
making them difficult to
secure
● Other timbers will be
straight and free of
knots making them easy
to secure
Ladder Settings
Correct (Minimum Capacity)
Correct (Maximum Capacity)
4.5”
1.5”
● 4 ½” is the largest sized log
this clamp can handle
● Lock the top plate into the
highest section of the
ladder
● As the handle begins to
feel snug complete one full
turn
● 1 ½” is the smallest
diameter that will fit
securely
● Lock the top plate into the
lowest section of the
ladder
● As the handle begins to
feel snug complete one full
turn
