3.2. Product Dimensions and Weight
Controller: 12.8 cm * 7.7 cm * 2.7 cm
Hand Piece: 14 cm
Drill Bit: Φ2.35 mm
1
Power Connector
When the power cord is plugged in, the unit will charge
automatically. Use only with Luraco 11.5V Charger.
2
Drill Controller
The drill controller is the heart of the system and
houses the control electronics and the battery.
3
Charge LED
Indicator
Blue light indicates the drill controller is being charged.
Off - The unit is not receiving external power.
4
Power Switch &
Speed Control
Turn the knob clockwise to turn on the unit and
increase the speed. Turn the knob counter-clockwise
to decrease speed.
Turn the knob counter-clockwise to the end to turn off
the unit.
5
Battery LED
Indicator
Green – Battery is good.
Flashing Green – Automatic shut down in 15 minutes.
Flashing red and green – Drill Control shuts down due
to drill overload current.
Flashing red – Battery is almost depleted.
Solid red – Battery is severely depleted and must be
recharged.
6
Drill Direction
Switch
Up (Forward) the spindle will rotate in the forward
direction.
Down (Reverse) the spindle will rotate in the reverse
direction.
7
Drill/Motor
Connector
Where the drill connects/disconnects.
Use only with the Luraco Pro-40K handpiece
8
Drill holder
Fully insert the drill here when it’s not in operation
9
Carrying Clip
Use this clip to carry the Pro-40K system on user’s
body
