Lutron Electronics LCR-9184 - Features; Specifications; General Specifications

1. FEATURES
* 19,999/1,999 counts dual LCD display.
* AutoLCR smart check and measurement.
* Serial/Parallel modes are selectable.
* Ls/Lp/Cs/Cp with D/Q/θ /ESR parameters.
* Support DCR mode 1.00 Ω to 200.0 MΩ .
* Five different test frequency are available :
100 Hz/120 Hz/1 KHz/10 KHz/100 KHz.
* Test AC signal level : 0.6 V rms typically.
* Test range : ( ex. F = 1 KHz )
L : 20.0 uH to 2000.0 H
C : 20.0 pF to 20.0 mF
R : 20.0Ω to 200.0 MΩ
* Multi-level battery detector.
* LCD with green light backlight，easy reading.
* RS232/USB PC Computer interface.
* Can default auto power off.
2. SPECIFICATIONS
2-1 General Specifications
Display LCD size：66.8 X 52.8 mm.
LCD with green backlight ( ON /OFF )
Test frequency 100 Hz/120 Hz/1 KHz/10 KHz/100 KHz
Function L/C/R Function selector
Frequency selector
D/Q/θ /ESR selector
Sorting mode selector
Backlight
Dissipation 0.000 to 1999
factor
Quality factor 0.000 to 1999
