Step 4b — Installation using the Junction Box Mount Adapter
Junction box
Junction box
Mud ring
RJ45 Connector (Ethernet Jack)
Junction box
mount adapter
Junction box
mount adapter
Junction box
Plug in Ethernet cable and attach processor to PoE-enabled network switch or
PoE injector
OR
Junction box
mount adapter
Ceiling installation
Wall installation
