GB
47
– Unscrew the tank lid (11) and remove.
– Carefully top up the fuel (tank contents:
Technical data – p. 50). Do not spill!
– Check the seal in the tank lid for dam-
ages, and clean if necessary. Immediately
replace damaged seals!
– Tighten the tank lid (11) by hand.
Filling with motor oil
P. 3, item 2
– Unscrew the motor oil filling screw (15)
and remove.
– Carefully top up the motor oil (tank con-
tents: Technical data – p. 50). Do not
spill!
– Tighten the motor oil filling screw (15) up
again by hand.
Set the cutting height
P. 5, item 6
The cutting height can be set to several differ-
ent heights (Cutting heights: Technical
data – p. 50).
– Pull the lever (6) to the side.
– Set the cutting height to the value you
require, and let the lever slot back into
place.
Attach the collection box
P. 5, item 7
– Lift the protective flap (7) and hold.
– Hook in the collection box (8).
– Make that the collection box is securely
engaged.
Mounting the ejection opening
P. 6, item 8
– Press the unlocking button (33).
– Lift the flap (25).
– Insert the ejection opening (5).
Mounting the mulching wedge
P. 6, item 9
– Remove the collection bag.
– Insert the mulching wedge (26) into the
opening of the unit until it engages.
– Lower the protective flap (7).
Operation
Check before starting the device!
Check to make sure the device is in safe
operating condition:
– Check to make sure there are no visible
defects.
– Check to make sure all device compo-
nents are correctly mounted.
Starting the motor
P. 3, item 2
– Engage and firmly hold the switch-on
bar (1) up to the stop.
– Slow pull out the pull starter (9) until you
feel a resistance, then quickly and force-
fully, until the initial ignition noise can be
heard.
– Pull out the pull starter again quickly and
forcefully until the motor starts up.
– Allow the engine to warm up for approx.
10–15 seconds.
Switching off the motor
P. 3, item 2
– Release the switch-on bar (1).
NOTICE! Risk of damage to the
device! The unit is delivered without
motor oil.
Motor oil must be filled before starting
the machine.
Note: Only use suitable fuels ( Fuel
and lubricants to be used – p. 51).
Note: When using the ejection open-
ing, the mulching wedge and collec-
tion bag are not needed.
Cut material is distributed across the
lawn.
DANGER! Risk of injury! The
device may only be put into operation
if there are no defects. If a part is
defective it must be replaced before
the device is used again.
DANGER! Danger of fire! Spilled
fuel can set the product on fire.
Carefully wipe up any spilled fuel up
before starting.
Start the product a minimum of nine
metres away from where you filled it.
Note: In case of start-up difficulties,
please refer to the following able:
Troubleshooting – p. 49
Note: Pull the pull starter out and
slowly guide it back using your hand.
WARNING! Risk of injury! Always
switch off the product when not in use
for short periods.
