Luxaire TC7B3021S - Page 39

5186767-LTG-B-0816
Johnson Controls Unitary Products 39
TC7B4821S TPLC100C20MP12 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B4821S TPLC120C20MP12 21.0 CF/CM/CU48C 1300 45.0 30.8 15.75 13.00
TC7B4821S TPLC120C20MP12 21.0 CF/CM/CU48D 1650 45.5 32.8 16.25 13.50
TC7B4821S TPLC120C20MP12 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S TPLC120C20MP12 21.0 CF/CM/CU60D 1350 45.5 31.4 16.00 13.25
TC7B4821S TPLC120C20MP12 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B4821S LP9C080C16MP12 21.0 CF/CM/CU48C 1425 45.5 32.4 15.75 13.00
TC7B4821S LP9C080C16MP12 21.0 CF/CM/CU48D 1425 46.0 32.6 16.25 13.25
TC7B4821S LP9C080C16MP12 21.0 CF/CM/CU60C 1350 45.5 31.6 16.00 13.25
TC7B4821S LP9C080C16MP12 21.0 CF/CM/CU60D 1425 46.0 33.0 16.00 13.25
TC7B4821S LP9C080C16MP12 21.0 CF/CM64D 1300 46.5 31.8 16.50 13.50
TC7B4821S LP9C100C16MP12 21.0 CF/CM/CU48C 1425 45.5 32.4 15.75 13.00
TC7B4821S LP9C100C16MP12 21.0 CF/CM/CU48D 1425 46.0 32.6 16.25 13.25
TC7B4821S LP9C100C16MP12 21.0 CF/CM/CU60C 1350 45.5 31.6 16.00 13.25
TC7B4821S LP9C100C16MP12 21.0 CF/CM/CU60D 1425 46.0 33.0 16.00 13.25
TC7B4821S LP9C100C16MP12 21.0 CF/CM64D 1300 46.5 31.8 16.50 13.50
TC7B4821S LP9C100C20MP12 21.0 CF/CM/CU48C 1450 45.5 32.2 15.25 12.75
TC7B4821S LP9C100C20MP12 21.0 CF/CM/CU48D 1300 45.0 30.8 15.75 13.00
TC7B4821S LP9C100C20MP12 21.0 CF/CM/CU60C 1450 46.0 33.2 15.75 13.00
TC7B4821S LP9C100C20MP12 21.0 CF/CM/CU60D 1325 46.0 32.0 16.25 13.50
TC7B4821S LP9C100C20MP12 21.0 CF/CM64D 1300 46.5 31.8 16.50 13.50
TC7B4821S LP9C120D20MP12 24.5 CF/CM/CU48D 1300 45.0 31.0 16.20 13.25
TC7B4821S LP9C120D20MP12 24.5 CF/CM/CU60D 1300 46.0 31.8 16.50 13.50
TC7B4821S LP9C120D20MP12 24.5 CF/CM64D 1525 47.0 34.6 16.25 13.25
TC7B4821S LPLC080C16MP12 21.0 CF/CM/CU48C 1325 44.5 30.6 15.75 13.00
TC7B4821S LPLC080C16MP12 21.0 CF/CM/CU48D 1300 45.0 30.8 15.75 13.00
TC7B4821S LPLC080C16MP12 21.0 CF/CM/CU60C 1325 45.5 31.6 16.25 13.25
TC7B4821S LPLC080C16MP12 21.0 CF/CM/CU60D 1325 45.5 31.6 16.25 13.50
TC7B4821S LPLC080C16MP12 21.0 CF/CM64D 1400 46.5 33.0 16.25 13.50
TC7B4821S LPLC100C16MP12 21.0 CF/CM/CU48C 1325 44.5 30.6 15.75 13.00
TC7B4821S LPLC100C16MP12 21.0 CF/CM/CU48D 1300 45.0 30.8 15.75 13.00
TC7B4821S LPLC100C16MP12 21.0 CF/CM/CU60C 1325 45.5 31.6 16.25 13.25
TC7B4821S LPLC100C16MP12 21.0 CF/CM/CU60D 1325 45.5 31.6 16.25 13.50
TC7B4821S LPLC100C16MP12 21.0 CF/CM64D 1400 46.5 33.0 16.25 13.50
TC7B4821S LPLC100C20MP12 21.0 CF/CM/CU48C 1300 45.0 30.8 15.75 13.00
TC7B4821S LPLC100C20MP12 21.0 CF/CM/CU48D 1650 45.5 32.8 16.25 13.50
TC7B4821S LPLC100C20MP12 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S LPLC100C20MP12 21.0 CF/CM/CU60D 1350 45.5 31.4 16.00 13.25
TC7B4821S LPLC100C20MP12 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B4821S LPLC120C20MP12 21.0 CF/CM/CU48C 1300 45.0 30.8 15.75 13.00
TC7B4821S LPLC120C20MP12 21.0 CF/CM/CU48D 1650 45.5 32.8 16.25 13.50
TC7B4821S LPLC120C20MP12 21.0 CF/CM/CU60C 1400 46.0 32.8 16.00 13.25
TC7B4821S LPLC120C20MP12 21.0 CF/CM/CU60D 1350 45.5 31.4 16.00 13.25
TC7B4821S LPLC120C20MP12 21.0 CF/CM64D 1425 47.0 33.4 16.25 13.25
TC7B6021S TM8V080C16MP11 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TM8V100C16MP11 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TM8V100C20MP11 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S TM8V120C20MP11 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S TM8X100C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TM8X100C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
TC7B6021S TM8X100C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TM8X120C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TM8X120C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
