5186767-LTG-B-0816
40 Johnson Controls Unitary Products
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
TC7B6021S TM8X120C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TM8Y100C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TM8Y100C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
TC7B6021S TM8Y100C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TM8Y120C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TM8Y120C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
TC7B6021S TM8Y120C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TM9E100C20MP11 21.0 CF/CM/CU60D 1625 56.0 39.0 14.75 12.25
TC7B6021S TM9E120D20MP11 24.5 CF/CM/CU60D 1625 56.0 39.0 15.00 12.50
TC7B6021S TM9V080C16MP11 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S TM9V080C16MP11 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S TM9V100C16MP11 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S TM9V100C16MP11 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S TM9V100C20MP11 21.0 CF/CM64D 1675 57.0 39.5 14.75 12.50
TC7B6021S TM9V120D20MP11 24.5 CF/CM/CU60D 1775 57.0 41.5 14.75 12.25
TC7B6021S TM9V120D20MP11 24.5 CF/CM64D 1750 58.0 41.0 14.75 12.50
TC7B6021S TM9Y100C20MP11 21.0 CF/CM/CU60D 1625 56.0 39.0 14.75 12.25
TC7B6021S TM9Y120D20MP11 24.5 CF/CM/CU60D 1625 56.0 39.0 15.00 12.50
TC7B6021S TMLV080C16MP11 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TMLV100C16MP11 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TMLV100C20MP11 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S TMLV120C20MP11 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S TMLX100C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TMLX100C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
TC7B6021S TMLX100C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TMLX120C20MP11 21.0 CF/CM/CU60C 1625 56.0 39.0 15.00 12.25
TC7B6021S TMLX120C20MP11 21.0 CF/CM/CU60D 1650 56.0 39.0 15.00 12.50
TC7B6021S TMLX120C20MP11 21.0 CF/CM64D 1625 57.5 40.0 15.50 12.75
TC7B6021S TP9C080C16MP12 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S TP9C080C16MP12 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S TP9C100C16MP12 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S TP9C100C16MP12 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S TP9C100C20MP12 21.0 CF/CM64D 1675 57.0 39.5 14.75 12.50
TC7B6021S TP9C120D20MP12 24.5 CF/CM/CU60D 1775 57.0 41.5 14.75 12.25
TC7B6021S TP9C120D20MP12 24.5 CF/CM64D 1750 58.0 41.0 14.75 12.50
TC7B6021S TPLC080C16MP12 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TPLC100C16MP12 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S TPLC100C20MP12 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S TPLC120C20MP12 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S LP9C080C16MP12 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S LP9C080C16MP12 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S LP9C100C16MP12 21.0 CF/CM/CU60C 1650 56.0 38.5 14.50 12.00
TC7B6021S LP9C100C16MP12 21.0 CF/CM64D 1650 57.5 39.5 15.00 12.50
TC7B6021S LP9C100C20MP12 21.0 CF/CM64D 1675 57.0 39.5 14.75 12.50
TC7B6021S LP9C120D20MP12 24.5 CF/CM/CU60D 1775 57.0 41.5 14.75 12.25
TC7B6021S LP9C120D20MP12 24.5 CF/CM64D 1750 58.0 41.0 14.75 12.50
TC7B6021S LPLC080C16MP12 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S LPLC100C16MP12 21.0 CF/CM64D 1650 57.0 39.5 14.75 12.50
TC7B6021S LPLC100C20MP12 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
TC7B6021S LPLC120C20MP12 21.0 CF/CM/CU60D 1700 56.0 39.5 14.25 12.00
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. High Efficiency Motor Furnaces have B.O.D (Blower Off Delay) standard.
2. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
