Luxaire TC7B3621S - Page 32

5186767-LTG-B-0816
32 Johnson Controls Unitary Products
TC7B4221S TM9V100C20MP11 21.0 CF/CM/CU60C 1275 42.0 29.2 16.50 13.50
TC7B4221S TM9V100C20MP11 21.0 CF/CM/CU60D 1250 42.0 29.0 16.50 13.75
TC7B4221S TM9V100C20MP11 21.0 CF/CM64D 1225 42.0 28.6 17.00 14.00
TC7B4221S TM9V120D20MP11 24.5 CF/CM/CU42D 1300 41.0 28.4 16.25 13.25
TC7B4221S TM9V120D20MP11 24.5 CF/CM/CU48D 1250 42.0 28.6 16.50 13.75
TC7B4221S TM9V120D20MP11 24.5 CF/CM/CU60D 1250 42.0 29.0 17.00 14.00
TC7B4221S TM9V120D20MP11 24.5 CF/CM64D 1250 42.0 29.0 17.00 14.00
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU42D 1200 40.5 27.4 16.20 13.25
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU48C 1200 41.0 27.4 16.25 13.50
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU48D 1200 42.0 28.4 16.50 13.75
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.50
TC7B4221S TM9Y080C16MP11 21.0 CF/CM/CU60D 1200 41.5 27.8 16.50 13.50
TC7B4221S TM9Y080C16MP11 21.0 CF/CM64D 1225 42.0 28.6 17.00 14.00
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU42D 1200 40.5 27.4 16.20 13.25
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU48C 1200 41.0 27.4 16.25 13.50
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU48D 1200 42.0 28.4 16.50 13.75
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU60C 1200 41.5 27.8 16.50 13.50
TC7B4221S TM9Y100C16MP11 21.0 CF/CM/CU60D 1200 41.5 27.8 16.50 13.50
TC7B4221S TM9Y100C16MP11 21.0 CF/CM64D 1225 42.0 28.6 17.00 14.00
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU42C 1225 41.0 28.4 16.50 13.50
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU42D 1250 41.0 28.4 16.50 13.50
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU48C 1225 41.5 28.2 16.50 13.75
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU48D 1225 42.0 28.4 16.50 13.75
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU60C 1225 42.0 28.8 16.50 13.75
TC7B4221S TM9Y100C20MP11 21.0 CF/CM/CU60D 1250 42.0 29.0 17.00 14.00
TC7B4221S TM9Y100C20MP11 21.0 CF/CM64D 1225 42.0 28.6 17.00 14.00
TC7B4221S TM9Y120D20MP11 24.5 CF/CM/CU42D 1250 41.0 28.4 16.50 13.50
TC7B4221S TM9Y120D20MP11 24.5 CF/CM/CU48D 1250 42.0 28.6 17.00 14.00
TC7B4221S TM9Y120D20MP11 24.5 CF/CM/CU60D 1225 42.0 28.8 17.00 14.00
TC7B4221S TM9Y120D20MP11 24.5 CF/CM64D 1225 42.0 28.6 17.00 14.25
TC7B4221S TMLV080C16MP11 21.0 CF/CM/CU42C 1325 41.0 28.8 16.00 13.00
TC7B4221S TMLV080C16MP11 21.0 CF/CM/CU48C 1325 42.0 29.2 16.25 13.50
TC7B4221S TMLV080C16MP11 21.0 CF/CM/CU48D 1300 42.0 29.0 16.50 13.75
TC7B4221S TMLV080C16MP11 21.0 CF/CM/CU60C 1325 42.0 29.8 16.50 13.75
TC7B4221S TMLV080C16MP11 21.0 CF/CM/CU60D 1325 42.0 29.8 16.50 13.75
TC7B4221S TMLV080C16MP11 21.0 CF/CM64D 1250 42.0 28.8 16.50 13.75
TC7B4221S TMLV100C16MP11 21.0 CF/CM/CU42C 1325 41.0 28.8 16.00 13.00
TC7B4221S TMLV100C16MP11 21.0 CF/CM/CU48C 1325 42.0 29.2 16.25 13.50
TC7B4221S TMLV100C16MP11 21.0 CF/CM/CU48D 1300 42.0 29.0 16.50 13.75
TC7B4221S TMLV100C16MP11 21.0 CF/CM/CU60C 1325 42.0 29.8 16.50 13.75
TC7B4221S TMLV100C16MP11 21.0 CF/CM/CU60D 1325 42.0 29.8 16.50 13.75
TC7B4221S TMLV100C16MP11 21.0 CF/CM64D 1250 42.0 28.8 16.50 13.75
TC7B4221S TMLV100C20MP11 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S TMLV100C20MP11 21.0 CF/CM/CU48C 1250 42.0 28.6 16.50 13.75
TC7B4221S TMLV100C20MP11 21.0 CF/CM/CU48D 1225 41.5 28.2 16.50 13.75
TC7B4221S TMLV100C20MP11 21.0 CF/CM/CU60C 1225 42.0 28.8 16.50 13.75
TC7B4221S TMLV100C20MP11 21.0 CF/CM/CU60D 1225 42.0 28.8 16.50 13.75
TC7B4221S TMLV100C20MP11 21.0 CF/CM64D 1200 41.5 27.8 16.50 13.75
TC7B4221S TMLV120C20MP11 21.0 CF/CM/CU42C 1225 41.0 27.8 16.25 13.25
TC7B4221S TMLV120C20MP11 21.0 CF/CM/CU48C 1250 42.0 28.6 16.50 13.75
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
