Luxaire TC7B3621S - Cooling Capacity - Air Handler Coils

5186767-LTG-B-0816
Johnson Controls Unitary Products 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
TC7B1821S AE18BX21 17.5 – 625 18.0 13.8 18.50 15.00
TC7B1821S AE24BX21 17.5 – 625 18.0 13.5 18.50 15.00
TC7B1821S AE30BX21 17.5 – 650 18.0 13.7 18.50 15.00
TC7B1821S AE36BX21 17.5 – 675 18.0 14.1 18.00 14.25
TC7B1821S AE36CX21 21.0 – 675 18.0 14.0 18.50 14.75
TC7B1821S AP18BX21 17.5 – 600 18.0 13.5 16.25 13.25
TC7B1821S AP24BX21 17.5 – 600 18.0 13.5 16.00 13.00
TC7B1821S AP30BX21 17.5 – 600 18.0 13.5 16.25 13.00
TC7B1821S AVC18BX21 17.5 – 600 18.0 13.6 18.00 14.50
TC7B1821S AVC24BX21 17.5 – 600 18.0 13.6 18.50 14.75
TC7B1821S AVC30BX21 17.5 – 600 18.0 13.5 18.50 15.00
TC7B1821S ME08BN21 17.5 CF/CM18B 600 18.0 13.7 18.50 15.00
TC7B1821S ME08BN21 17.5 CF/CM24B 600 18.0 13.6 18.50 15.00
TC7B1821S ME08BN21 17.5 CF/CM30B 600 18.0 13.5 18.50 15.00
TC7B1821S ME08BN21 17.5 CF/CM36B 600 18.0 13.6 18.50 15.00
TC7B1821S ME12BN21 17.5 CF/CM18B 675 18.0 14.2 17.00 13.75
TC7B1821S ME12BN21 17.5 CF/CM24B 675 18.0 14.1 17.00 14.00
TC7B1821S ME12BN21 17.5 CF/CM30B 675 18.0 14.0 17.50 14.25
TC7B1821S ME12BN21 17.5 CF/CM36B 675 18.0 14.0 17.50 14.25
TC7B1821S MVC08BN21 17.5 CF/CM18B 600 18.0 13.7 18.00 14.75
TC7B1821S MVC08BN21 17.5 CF/CM24B 625 18.0 14.1 18.50 15.00
TC7B1821S MVC08BN21 17.5 CF/CM30B 625 18.0 14.0 18.50 15.00
TC7B1821S MVC08BN21 17.5 CF/CM36B 625 18.0 14.0 18.50 14.75
TC7B1821S MVC12BN21 17.5 CF/CM36B 675 18.0 14.0 18.50 14.75
TC7B2421S AE24BX21 17.5 – 800 24.0 18.4 17.50 14.25
TC7B2421S AE30BX21 17.5 – 825 24.0 18.5 18.00 14.75
TC7B2421S AE36BX21 17.5 – 825 24.0 18.5 18.50 15.00
TC7B2421S AE36CX21 21.0 – 850 24.0 18.6 18.50 15.00
TC7B2421S AP24BX21 17.5 – 775 23.6 17.8 15.50 12.75
TC7B2421S AP30BX21 17.5 – 800 24.0 18.1 16.50 13.50
TC7B2421S AP36BX21 17.5 – 900 24.0 19.2 16.00 13.00
TC7B2421S AP36CX21 21.0 – 850 24.0 18.6 16.00 13.00
TC7B2421S AVC24BX21 17.5 – 675 23.6 17.0 17.50 14.25
TC7B2421S AVC30BX21 17.5 – 750 24.0 18.1 18.50 14.75
TC7B2421S AVC36BX21 17.5 – 800 24.0 18.3 18.50 15.00
TC7B2421S AVC36CX21 21.0 – 850 24.0 19.1 18.50 15.00
TC7B2421S ME08BN21 17.5 CF/CM24B 825 24.0 18.7 18.00 14.50
TC7B2421S ME08BN21 17.5 CF/CM30B 825 24.0 18.6 18.50 15.00
TC7B2421S ME08BN21 17.5 CF/CM36B 825 24.0 18.7 18.50 15.00
TC7B2421S ME08BN21 17.5 CF42B 775 24.0 18.0 18.50 14.75
TC7B2421S ME12BN21 17.5 CF/CM24B 825 24.0 18.8 17.50 14.50
TC7B2421S ME12BN21 17.5 CF/CM30B 825 24.0 18.6 18.00 14.50
TC7B2421S ME12BN21 17.5 CF/CM36B 825 24.0 18.8 18.50 14.75
TC7B2421S ME12BN21 17.5 CF42B 800 24.0 18.1 18.00 14.75
TC7B2421S ME14DN21 24.5 CF/CM30D 900 24.0 19.3 17.50 14.25
TC7B2421S ME14DN21 24.5 CF/CM36D 900 24.0 19.2 18.00 14.50
TC7B2421S ME14DN21 24.5 CF/CM42D 900 24.0 19.0 18.00 14.75
TC7B2421S ME16CN21 21.0 CF/CM24C 900 24.0 19.1 16.25 13.25
TC7B2421S MVC08BN21 17.5 CF/CM24B 700 23.4 17.1 17.50 14.25
TC7B2421S MVC08BN21 17.5 CF/CM30B 725 24.0 17.8 18.00 14.50
TC7B2421S MVC08BN21 17.5 CF/CM36B 750 24.0 17.8 17.50 14.25
TC7B2421S MVC08BN21 17.5 CF42B 725 24.0 17.6 17.50 14.50
TC7B2421S MVC12BN21 17.5 CF/CM24B 800 24.0 18.3 17.50 14.00
Continued on next page.
