Luxaire TC7B3621S - Page 46

5186767-LTG-B-0816
46 Johnson Controls Unitary Products
COIL MULTIPLIERS- 1.5 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU18A 1.00 1.00 1.00
– CF/CM/CU18B 1.00 1.00 1.00
– CF/CM/CU24A 1.01 1.01 1.01
– CF/CM/CU24B 1.01 1.01 1.01
– CF/CM/CU30A 1.01 1.00 0.99
– CF/CM/CU30B 1.01 1.00 0.99
– CF/CM/CU30C 1.01 1.00 0.99
– CF/CM/CU30D 1.01 1.00 0.99
– CF/CM36A 1.01 1.01 0.99
– CF/CM/CU36B 1.01 1.01 0.99
– CF/CM/CU36C 1.01 1.01 0.99
– CF/CM/CU36D 1.01 1.01 0.99
– CF/CM/CU24C 1.01 1.01 1.01
AE18BX21 – 1.01 1.03 0.86
AE24BX21 – 1.01 1.01 0.86
AE30BX21 – 1.01 1.02 0.86
AE36BX21 – 1.01 1.05 0.90
AE36CX21 – 1.01 1.04 0.87
AP18BX21 – 1.01 1.01 0.97
AP24BX21 – 1.01 1.01 0.99
AP30BX21 – 1.01 1.01 0.99
AVC18BX21 – 1.01 1.01 0.89
AVC24BX21 – 1.01 1.01 0.87
AVC30BX21 – 1.01 1.00 0.86
ME08BN21 CF/CM18B 1.01 1.02 0.86
ME08BN21 CF/CM24B 1.01 1.01 0.86
ME08BN21 CF/CM30B 1.01 1.00 0.86
ME08BN21 CF/CM36B 1.01 1.01 0.86
ME12BN21 CF/CM18B 1.01 1.06 0.94
ME12BN21 CF/CM24B 1.01 1.05 0.92
ME12BN21 CF/CM30B 1.01 1.04 0.90
ME12BN21 CF/CM36B 1.01 1.04 0.90
MVC08BN21 CF/CM18B 1.01 1.02 0.87
MVC08BN21 CF/CM24B 1.01 1.05 0.86
MVC08BN21 CF/CM30B 1.01 1.04 0.86
MVC08BN21 CF/CM36B 1.01 1.04 0.87
MVC12BN21 CF/CM36B 1.01 1.04 0.87
FURNACE MULTIPLIERS- 1.5 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP11 CF/CM/CU18A 1.00 0.95 0.93
TM8V060A12MP11 CF/CM/CU24A 1.01 0.98 0.92
TM8V060A12MP11 CF/CM/CU30A 1.01 0.97 0.90
TM8V080B12MP11 CF/CM/CU18B 1.01 1.04 0.90
TM8V080B12MP11 CF/CM/CU24B 1.01 1.05 0.89
TM8V080B12MP11 CF/CM/CU30B 1.01 1.02 0.89
TM8V080B12MP11 CF/CM/CU36B 1.01 1.05 0.87
TM8X060A12MP11 CF/CM/CU18A 1.01 1.06 0.89
TM8X060A12MP11 CF/CM/CU24A 1.01 1.05 0.89
TM8X060A12MP11 CF/CM/CU30A 1.01 1.05 0.86
TM8X060A12MP11 CF/CM36A 1.01 1.05 0.86
TM8X080B12MP11 CF/CM/CU18B 1.01 1.06 0.89
TM8X080B12MP11 CF/CM/CU24B 1.01 1.05 0.89
TM8X080B12MP11 CF/CM/CU30B 1.01 1.05 0.86
TM8X080B12MP11 CF/CM/CU36B 1.01 1.05 0.86
TM8X080C16MP11 CF/CM/CU30C 1.01 1.04 0.87
TM8X080C16MP11 CF/CM/CU30D 1.01 1.04 0.87
TM8X080C16MP11 CF/CM/CU36C 1.01 1.04 0.89
TM8X080C16MP11 CF/CM/CU36D 1.01 1.04 0.89
TM8X080C16MP11 CF/CM/CU24C 1.01 1.05 0.89
TM8X100C16MP11 CF/CM/CU30C 1.01 1.04 0.87
TM8X100C16MP11 CF/CM/CU30D 1.01 1.04 0.87
TM8X100C16MP11 CF/CM/CU36C 1.01 1.04 0.89
TM8X100C16MP11 CF/CM/CU36D 1.01 1.04 0.89
TM8X100C16MP11 CF/CM/CU24C 1.01 1.05 0.89
TM8Y060A12MP11 CF/CM/CU18A 1.01 1.06 0.89
TM8Y060A12MP11 CF/CM/CU24A 1.01 1.05 0.89
TM8Y060A12MP11 CF/CM/CU30A 1.01 1.05 0.86
TM8Y060A12MP11 CF/CM36A 1.01 1.05 0.86
TM8Y080B12MP11 CF/CM/CU18B 1.01 1.06 0.89
TM8Y080B12MP11 CF/CM/CU24B 1.01 1.05 0.89
TM8Y080B12MP11 CF/CM/CU30B 1.01 1.05 0.86
TM8Y080B12MP11 CF/CM/CU36B 1.01 1.05 0.86
TM8Y080C16MP11 CF/CM/CU30C 1.01 1.04 0.87
TM8Y080C16MP11 CF/CM/CU30D 1.01 1.04 0.87
TM8Y080C16MP11 CF/CM/CU36C 1.01 1.04 0.89
TM8Y080C16MP11 CF/CM/CU36D 1.01 1.04 0.89
TM8Y080C16MP11 CF/CM/CU24C 1.01 1.05 0.89
TM8Y100C16MP11 CF/CM/CU30C 1.01 1.04 0.87
TM8Y100C16MP11 CF/CM/CU30D 1.01 1.04 0.87
TM8Y100C16MP11 CF/CM/CU36C 1.01 1.04 0.89
TM8Y100C16MP11 CF/CM/CU36D 1.01 1.04 0.89
TM8Y100C16MP11 CF/CM/CU24C 1.01 1.05 0.89
TM9E040A10MP11 CF/CM/CU18A 1.01 1.01 0.90
TM9E040A10MP11 CF/CM/CU24A 1.01 0.99 0.90
TM9E040A10MP11 CF/CM/CU30A 1.01 1.01 0.89
TM9E040A10MP11 CF/CM36A 1.01 1.01 0.89
TM9E060B12MP11 CF/CM/CU18B 1.01 1.06 0.90
TM9E060B12MP11 CF/CM/CU24B 1.01 1.05 0.90
TM9E060B12MP11 CF/CM/CU30B 1.01 1.04 0.87
TM9E060B12MP11 CF/CM/CU36B 1.01 1.04 0.87
TM9E080B12MP11 CF/CM/CU18B 1.01 1.06 0.90
TM9E080B12MP11 CF/CM/CU24B 1.01 1.05 0.90
TM9E080B12MP11 CF/CM/CU30B 1.01 1.04 0.87
TM9E080B12MP11 CF/CM/CU36B 1.01 1.04 0.87
TM9E080C16MP11 CF/CM/CU30C 1.01 1.05 0.86
TM9E080C16MP11 CF/CM/CU30D 1.01 1.05 0.86
TM9E080C16MP11 CF/CM/CU36C 1.01 1.04 0.86
TM9E080C16MP11 CF/CM/CU36D 1.01 1.04 0.86
TM9E080C16MP11 CF/CM/CU24C 1.01 1.05 0.87
TM9E100C16MP11 CF/CM/CU30C 1.01 1.05 0.86
TM9E100C16MP11 CF/CM/CU30D 1.01 1.05 0.86
TM9E100C16MP11 CF/CM/CU36C 1.01 1.04 0.86
TM9E100C16MP11 CF/CM/CU36D 1.01 1.04 0.86
TM9E100C16MP11 CF/CM/CU24C 1.01 1.05 0.87
TM9E100C20MP11 CF/CM/CU30C 1.01 1.05 0.94
TM9E100C20MP11 CF/CM/CU30D 1.01 1.05 0.96
TM9E100C20MP11 CF/CM/CU36C 1.01 1.04 0.96
TM9E100C20MP11 CF/CM/CU36D 1.01 1.04 0.96
TM9E100C20MP11 CF/CM/CU24C 1.01 1.05 0.96
TM9E120D20MP11 CF/CM/CU30D 1.01 1.05 0.94
TM9E120D20MP11 CF/CM/CU36D 1.01 1.04 0.94
TM9V040A10MP11 CF/CM/CU24A 1.01 1.04 0.97
TM9V060B12MP11 CF/CM/CU18B 1.01 0.98 0.89
FURNACE MULTIPLIERS- 1.5 TON (Continued)
Furnaces Coil T.C. S.C. KW
