Luxaire TC7B3621S - Page 58

5186767-LTG-B-0816
58 Johnson Controls Unitary Products
TM8X100C20MP11 CF/CM/CU42C 0.98 0.94 0.90
TM8X100C20MP11 CF/CM/CU42D 0.98 0.96 0.90
TM8X100C20MP11 CF/CM/CU48C 1.00 0.97 0.91
TM8X100C20MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8X100C20MP11 CF/CM/CU60C 1.00 0.97 0.89
TM8X100C20MP11 CF/CM/CU60D 1.00 0.96 0.89
TM8X120C20MP11 CF/CM/CU36C 0.96 0.93 0.89
TM8X120C20MP11 CF/CM/CU36D 0.96 0.95 0.89
TM8X120C20MP11 CF/CM/CU42C 0.98 0.94 0.90
TM8X120C20MP11 CF/CM/CU42D 0.98 0.96 0.90
TM8X120C20MP11 CF/CM/CU48C 1.00 0.97 0.91
TM8X120C20MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8X120C20MP11 CF/CM/CU60C 1.00 0.97 0.89
TM8X120C20MP11 CF/CM/CU60D 1.00 0.96 0.89
TM8Y060A12MP11 CF/CM36A 0.96 0.90 0.92
TM8Y080B12MP11 CF/CM/CU36B 0.96 0.89 0.91
TM8Y080B12MP11 CF42B 0.98 0.92 0.93
TM8Y080C16MP11 CF/CM/CU36C 0.96 0.92 0.89
TM8Y080C16MP11 CF/CM/CU36D 0.96 0.93 0.89
TM8Y080C16MP11 CF/CM/CU42C 0.98 0.93 0.91
TM8Y080C16MP11 CF/CM/CU42D 0.98 0.94 0.90
TM8Y080C16MP11 CF/CM/CU48C 1.00 0.96 0.91
TM8Y080C16MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8Y080C16MP11 CF/CM/CU60C 1.00 0.96 0.91
TM8Y080C16MP11 CF/CM/CU60D 1.00 0.96 0.91
TM8Y100C16MP11 CF/CM/CU36C 0.96 0.92 0.89
TM8Y100C16MP11 CF/CM/CU36D 0.96 0.93 0.89
TM8Y100C16MP11 CF/CM/CU42C 0.98 0.93 0.91
TM8Y100C16MP11 CF/CM/CU42D 0.98 0.94 0.90
TM8Y100C16MP11 CF/CM/CU48C 1.00 0.96 0.91
TM8Y100C16MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8Y100C16MP11 CF/CM/CU60C 1.00 0.96 0.91
TM8Y100C16MP11 CF/CM/CU60D 1.00 0.96 0.91
TM8Y100C20MP11 CF/CM/CU36C 0.96 0.93 0.89
TM8Y100C20MP11 CF/CM/CU36D 0.96 0.95 0.89
TM8Y100C20MP11 CF/CM/CU42C 0.98 0.94 0.90
TM8Y100C20MP11 CF/CM/CU42D 0.98 0.96 0.90
TM8Y100C20MP11 CF/CM/CU48C 1.00 0.97 0.91
TM8Y100C20MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8Y100C20MP11 CF/CM/CU60C 1.00 0.97 0.89
TM8Y100C20MP11 CF/CM/CU60D 1.00 0.96 0.89
TM8Y120C20MP11 CF/CM/CU36C 0.96 0.93 0.89
TM8Y120C20MP11 CF/CM/CU36D 0.96 0.95 0.89
TM8Y120C20MP11 CF/CM/CU42C 0.98 0.94 0.90
TM8Y120C20MP11 CF/CM/CU42D 0.98 0.96 0.90
TM8Y120C20MP11 CF/CM/CU48C 1.00 0.97 0.91
TM8Y120C20MP11 CF/CM/CU48D 1.00 0.97 0.91
TM8Y120C20MP11 CF/CM/CU60C 1.00 0.97 0.89
TM8Y120C20MP11 CF/CM/CU60D 1.00 0.96 0.89
TM9E060B12MP11 CF/CM/CU36B 0.96 0.90 0.92
TM9E060B12MP11 CF42B 0.98 0.92 0.95
TM9E080B12MP11 CF/CM/CU36B 0.96 0.90 0.92
TM9E080B12MP11 CF42B 0.98 0.92 0.95
TM9E080C16MP11 CF/CM/CU36C 0.96 0.93 0.91
TM9E080C16MP11 CF/CM/CU36D 0.96 0.93 0.91
FURNACE MULTIPLIERS- 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
TM9E080C16MP11 CF/CM/CU42C 0.98 0.94 0.91
TM9E080C16MP11 CF/CM/CU42D 0.98 0.94 0.91
TM9E080C16MP11 CF/CM/CU48C 1.00 0.97 0.93
TM9E080C16MP11 CF/CM/CU48D 1.00 0.97 0.91
TM9E080C16MP11 CF/CM/CU60C 1.00 0.97 0.91
TM9E080C16MP11 CF/CM/CU60D 1.00 0.97 0.91
TM9E100C16MP11 CF/CM/CU36C 0.96 0.93 0.91
TM9E100C16MP11 CF/CM/CU36D 0.96 0.93 0.91
TM9E100C16MP11 CF/CM/CU42C 0.98 0.94 0.91
TM9E100C16MP11 CF/CM/CU42D 0.98 0.94 0.91
TM9E100C16MP11 CF/CM/CU48C 1.00 0.97 0.93
TM9E100C16MP11 CF/CM/CU48D 1.00 0.97 0.91
TM9E100C16MP11 CF/CM/CU60C 1.00 0.97 0.91
TM9E100C16MP11 CF/CM/CU60D 1.00 0.97 0.91
TM9E100C20MP11 CF/CM/CU36C 0.96 0.89 0.89
TM9E100C20MP11 CF/CM/CU36D 0.96 0.89 0.89
TM9E100C20MP11 CF/CM/CU42C 0.98 0.92 0.91
TM9E100C20MP11 CF/CM/CU42D 0.98 0.92 0.91
TM9E100C20MP11 CF/CM/CU48C 1.00 0.95 0.91
TM9E100C20MP11 CF/CM/CU48D 1.00 0.95 0.91
TM9E100C20MP11 CF/CM/CU60C 1.00 1.01 0.91
TM9E100C20MP11 CF/CM/CU60D 1.00 0.93 0.91
TM9E120D20MP11 CF/CM/CU36D 0.96 0.89 0.88
TM9E120D20MP11 CF/CM/CU42D 0.98 0.92 0.90
TM9E120D20MP11 CF/CM/CU48D 1.00 0.94 0.91
TM9E120D20MP11 CF/CM/CU60D 1.00 0.93 0.89
TM9V060B12MP11 CF/CM/CU36B 0.96 0.92 0.92
TM9V060B12MP11 CF42B 0.98 0.93 0.93
TM9V080B12MP11 CF/CM/CU36B 0.96 0.92 0.92
TM9V080B12MP11 CF42B 0.98 0.93 0.93
TM9V080C16MP11 CF/CM/CU36C 0.96 0.90 0.89
TM9V080C16MP11 CF/CM/CU42C 0.98 0.92 0.91
TM9V080C16MP11 CF/CM/CU48C 1.00 1.01 0.93
TM9V080C16MP11 CF/CM/CU48D 1.00 1.00 0.91
TM9V080C16MP11 CF/CM/CU60C 1.00 1.00 0.91
TM9V080C16MP11 CF/CM/CU60D 1.00 0.97 0.91
TM9V100C16MP11 CF/CM/CU36C 0.96 0.90 0.89
TM9V100C16MP11 CF/CM/CU42C 0.98 0.92 0.91
TM9V100C16MP11 CF/CM/CU48C 1.00 1.01 0.93
TM9V100C16MP11 CF/CM/CU48D 1.00 1.00 0.91
TM9V100C16MP11 CF/CM/CU60C 1.00 1.00 0.91
TM9V100C16MP11 CF/CM/CU60D 1.00 0.97 0.91
TM9V100C20MP11 CF/CM/CU36C 0.96 0.93 0.91
TM9V100C20MP11 CF/CM/CU42C 0.98 0.98 0.95
TM9V100C20MP11 CF/CM/CU48C 1.00 1.00 0.94
TM9V100C20MP11 CF/CM/CU48D 1.00 1.04 0.93
TM9V100C20MP11 CF/CM/CU60C 1.00 0.99 0.94
TM9V100C20MP11 CF/CM/CU60D 1.00 1.01 0.91
TM9V120D20MP11 CF/CM/CU36D 0.96 0.94 0.86
TM9V120D20MP11 CF/CM/CU42D 0.98 0.96 0.91
TM9V120D20MP11 CF/CM/CU48D 1.00 1.02 0.93
TM9V120D20MP11 CF/CM/CU60D 1.00 1.01 0.91
TM9Y060B12MP11 CF/CM/CU36B 0.96 0.90 0.92
TM9Y060B12MP11 CF42B 0.98 0.92 0.95
TM9Y080B12MP11 CF/CM/CU36B 0.96 0.90 0.92
FURNACE MULTIPLIERS- 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
