Luxaire TC7B3621S - Page 63

5186767-LTG-B-0816
Johnson Controls Unitary Products 63
TM8Y080C16MP11 CF/CM/CU42D 0.99 0.95 0.93
TM8Y080C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM8Y080C16MP11 CF/CM/CU48D 0.99 0.94 0.93
TM8Y080C16MP11 CF/CM/CU60C 1.00 0.95 0.93
TM8Y080C16MP11 CF/CM/CU60D 1.01 0.98 0.92
TM8Y080C16MP11 CF/CM64D 1.01 0.96 0.94
TM8Y100C16MP11 CF/CM/CU42C 0.98 0.92 0.94
TM8Y100C16MP11 CF/CM/CU42D 0.99 0.95 0.93
TM8Y100C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM8Y100C16MP11 CF/CM/CU48D 0.99 0.94 0.93
TM8Y100C16MP11 CF/CM/CU60C 1.00 0.95 0.93
TM8Y100C16MP11 CF/CM/CU60D 1.01 0.98 0.92
TM8Y100C16MP11 CF/CM64D 1.01 0.96 0.94
TM8Y100C20MP11 CF/CM/CU42C 0.99 0.97 0.93
TM8Y100C20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM8Y100C20MP11 CF/CM/CU48C 1.01 0.99 0.92
TM8Y100C20MP11 CF/CM/CU48D 1.01 0.98 0.92
TM8Y100C20MP11 CF/CM/CU60C 1.01 1.01 0.92
TM8Y100C20MP11 CF/CM/CU60D 1.01 1.01 0.92
TM8Y100C20MP11 CF/CM64D 1.01 0.99 0.91
TM8Y120C20MP11 CF/CM/CU42C 0.99 0.97 0.93
TM8Y120C20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM8Y120C20MP11 CF/CM/CU48C 1.01 0.99 0.92
TM8Y120C20MP11 CF/CM/CU48D 1.01 0.98 0.92
TM8Y120C20MP11 CF/CM/CU60C 1.01 1.01 0.92
TM8Y120C20MP11 CF/CM/CU60D 1.01 1.01 0.92
TM8Y120C20MP11 CF/CM64D 1.01 0.99 0.91
TM9E080C16MP11 CF/CM/CU42C 0.99 0.95 0.95
TM9E080C16MP11 CF/CM/CU42D 0.98 0.94 0.94
TM9E080C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM9E080C16MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9E080C16MP11 CF/CM/CU60C 1.00 0.95 0.94
TM9E080C16MP11 CF/CM/CU60D 1.00 0.95 0.94
TM9E080C16MP11 CF/CM64D 1.01 0.98 0.92
TM9E100C16MP11 CF/CM/CU42C 0.99 0.95 0.95
TM9E100C16MP11 CF/CM/CU42D 0.98 0.94 0.94
TM9E100C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM9E100C16MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9E100C16MP11 CF/CM/CU60C 1.00 0.95 0.94
TM9E100C16MP11 CF/CM/CU60D 1.00 0.95 0.94
TM9E100C16MP11 CF/CM64D 1.01 0.98 0.92
TM9E100C20MP11 CF/CM/CU42C 0.99 0.97 0.93
TM9E100C20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM9E100C20MP11 CF/CM/CU48C 1.00 0.96 0.93
TM9E100C20MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9E100C20MP11 CF/CM/CU60C 1.01 0.98 0.94
TM9E100C20MP11 CF/CM/CU60D 1.01 0.99 0.92
TM9E100C20MP11 CF/CM64D 1.01 0.98 0.92
TM9E120D20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM9E120D20MP11 CF/CM/CU48D 1.01 0.98 0.92
TM9E120D20MP11 CF/CM/CU60D 1.01 0.98 0.92
TM9E120D20MP11 CF/CM64D 1.01 0.98 0.91
TM9V060B12MP11 CF42B 0.98 0.96 1.00
TM9V080B12MP11 CF42B 0.98 0.96 1.00
TM9V080C16MP11 CF/CM/CU42C 0.99 0.97 0.95
FURNACE MULTIPLIERS- 3.5 TON (Continued)
Furnaces Coil T.C. S.C. KW
TM9V080C16MP11 CF/CM/CU48C 1.01 0.98 0.96
TM9V080C16MP11 CF/CM/CU48D 1.00 0.95 0.93
TM9V080C16MP11 CF/CM/CU60C 1.00 0.95 0.93
TM9V080C16MP11 CF/CM/CU60D 1.01 1.04 0.96
TM9V080C16MP11 CF/CM64D 1.01 1.01 0.94
TM9V100C16MP11 CF/CM/CU42C 0.99 0.97 0.95
TM9V100C16MP11 CF/CM/CU48C 1.01 0.98 0.96
TM9V100C16MP11 CF/CM/CU48D 1.00 0.95 0.93
TM9V100C16MP11 CF/CM/CU60C 1.00 0.95 0.93
TM9V100C16MP11 CF/CM/CU60D 1.01 1.04 0.96
TM9V100C16MP11 CF/CM64D 1.01 1.01 0.94
TM9V100C20MP11 CF/CM/CU42C 0.99 0.97 0.97
TM9V100C20MP11 CF/CM/CU48C 1.01 0.98 0.96
TM9V100C20MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9V100C20MP11 CF/CM/CU60C 1.01 1.00 0.96
TM9V100C20MP11 CF/CM/CU60D 1.01 0.99 0.94
TM9V100C20MP11 CF/CM64D 1.01 0.98 0.92
TM9V120D20MP11 CF/CM/CU42D 0.99 0.97 0.95
TM9V120D20MP11 CF/CM/CU48D 1.01 0.98 0.94
TM9V120D20MP11 CF/CM/CU60D 1.01 0.99 0.92
TM9V120D20MP11 CF/CM64D 1.01 0.99 0.92
TM9Y080C16MP11 CF/CM/CU42C 0.99 0.95 0.95
TM9Y080C16MP11 CF/CM/CU42D 0.98 0.94 0.94
TM9Y080C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM9Y080C16MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9Y080C16MP11 CF/CM/CU60C 1.00 0.95 0.94
TM9Y080C16MP11 CF/CM/CU60D 1.00 0.95 0.94
TM9Y080C16MP11 CF/CM64D 1.01 0.98 0.92
TM9Y100C16MP11 CF/CM/CU42C 0.99 0.95 0.95
TM9Y100C16MP11 CF/CM/CU42D 0.98 0.94 0.94
TM9Y100C16MP11 CF/CM/CU48C 0.99 0.94 0.93
TM9Y100C16MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9Y100C16MP11 CF/CM/CU60C 1.00 0.95 0.94
TM9Y100C16MP11 CF/CM/CU60D 1.00 0.95 0.94
TM9Y100C16MP11 CF/CM64D 1.01 0.98 0.92
TM9Y100C20MP11 CF/CM/CU42C 0.99 0.97 0.93
TM9Y100C20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM9Y100C20MP11 CF/CM/CU48C 1.00 0.96 0.93
TM9Y100C20MP11 CF/CM/CU48D 1.01 0.97 0.94
TM9Y100C20MP11 CF/CM/CU60C 1.01 0.98 0.94
TM9Y100C20MP11 CF/CM/CU60D 1.01 0.99 0.92
TM9Y100C20MP11 CF/CM64D 1.01 0.98 0.92
TM9Y120D20MP11 CF/CM/CU42D 0.99 0.97 0.93
TM9Y120D20MP11 CF/CM/CU48D 1.01 0.98 0.92
TM9Y120D20MP11 CF/CM/CU60D 1.01 0.98 0.92
TM9Y120D20MP11 CF/CM64D 1.01 0.98 0.91
TMLV080C16MP11 CF/CM/CU42C 0.99 0.99 0.97
TMLV080C16MP11 CF/CM/CU48C 1.01 1.00 0.96
TMLV080C16MP11 CF/CM/CU48D 1.01 0.99 0.94
TMLV080C16MP11 CF/CM/CU60C 1.01 1.02 0.94
TMLV080C16MP11 CF/CM/CU60D 1.01 1.02 0.94
TMLV080C16MP11 CF/CM64D 1.01 0.99 0.94
TMLV100C16MP11 CF/CM/CU42C 0.99 0.99 0.97
TMLV100C16MP11 CF/CM/CU48C 1.01 1.00 0.96
TMLV100C16MP11 CF/CM/CU48D 1.01 0.99 0.94
FURNACE MULTIPLIERS- 3.5 TON (Continued)
Furnaces Coil T.C. S.C. KW
