Luxaire TC7B3621S - Page 67

5186767-LTG-B-0816
Johnson Controls Unitary Products 67
COIL MULTIPLIERS- 4 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU48C 0.99 0.97 1.03
– CF/CM/CU48D 0.99 0.97 1.03
– CF/CM/CU60C 1.00 1.00 1.00
– CF/CM/CU60D 1.01 1.01 1.01
– CF/CM64D 1.03 1.03 1.01
AE48CX21 – 1.00 0.98 0.96
AE48DX21 – 1.01 0.99 0.94
AE60CX21 – 1.02 1.02 0.95
AE60DX21 – 1.03 1.02 0.94
AP48CX21 – 0.98 0.92 1.00
AP48DX21 – 0.99 0.96 1.01
AP60CX21 – 1.01 1.01 1.03
AP60DX21 – 1.01 1.03 1.03
AVC48CX21 – 1.00 0.96 0.96
AVC48DX21 – 1.01 0.98 0.94
AVC60CX21 – 1.01 0.98 0.94
AVC60DX21 – 1.02 0.97 0.95
ME14DN21 CF/CM60D 1.02 1.01 0.95
ME14DN21 CF/CM64D 1.03 1.00 0.96
ME16CN21 CF/CM48C 1.01 1.01 0.95
ME16CN21 CF/CM60C 1.02 1.02 0.95
ME20DN21 CF/CM48D 1.01 0.99 0.94
ME20DN21 CF/CM60D 1.02 1.02 0.95
ME20DN21 CF/CM64D 1.03 1.02 0.96
MVC14DN21 CF/CM48D 1.00 0.93 0.94
MVC16CN21 CF/CM48C 1.00 0.95 0.94
MVC16CN21 CF/CM60C 1.00 0.96 0.93
MVC20DN21 CF/CM48D 1.00 0.95 0.94
MVC20DN21 CF/CM60D 1.02 0.99 0.95
MVC20DN21 CF/CM64D 1.02 0.99 0.93
FURNACE MULTIPLIERS- 4 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP11 CF/CM/CU48C 0.98 0.93 0.96
TM8V080C16MP11 CF/CM/CU48D 0.99 0.93 0.97
TM8V080C16MP11 CF/CM/CU60C 1.00 0.96 0.96
TM8V080C16MP11 CF/CM/CU60D 1.00 0.96 0.94
TM8V080C16MP11 CF/CM64D 1.02 1.00 0.97
TM8V100C16MP11 CF/CM/CU48C 0.98 0.93 0.96
TM8V100C16MP11 CF/CM/CU48D 0.99 0.93 0.97
TM8V100C16MP11 CF/CM/CU60C 1.00 0.96 0.96
TM8V100C16MP11 CF/CM/CU60D 1.00 0.96 0.94
TM8V100C16MP11 CF/CM64D 1.02 1.00 0.97
TM8V100C20MP11 CF/CM/CU48C 0.99 0.93 0.97
TM8V100C20MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8V100C20MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8V100C20MP11 CF/CM/CU60D 1.00 0.95 0.96
TM8V100C20MP11 CF/CM64D 1.03 1.01 0.99
TM8V120C20MP11 CF/CM/CU48C 0.99 0.93 0.97
TM8V120C20MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8V120C20MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8V120C20MP11 CF/CM/CU60D 1.00 0.95 0.96
TM8V120C20MP11 CF/CM64D 1.03 1.01 0.99
TM8X080C16MP11 CF/CM/CU48C 1.00 0.97 0.98
TM8X080C16MP11 CF/CM/CU48D 1.00 0.98 0.98
TM8X080C16MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8X080C16MP11 CF/CM/CU60D 1.02 1.00 0.98
TM8X080C16MP11 CF/CM64D 1.02 1.00 0.97
TM8X100C16MP11 CF/CM/CU48C 1.00 0.97 0.98
TM8X100C16MP11 CF/CM/CU48D 1.00 0.98 0.98
TM8X100C16MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8X100C16MP11 CF/CM/CU60D 1.02 1.00 0.98
TM8X100C16MP11 CF/CM64D 1.02 1.00 0.97
TM8X100C20MP11 CF/CM/CU48C 1.00 0.98 0.96
TM8X100C20MP11 CF/CM/CU48D 0.99 0.95 0.93
TM8X100C20MP11 CF/CM/CU60C 1.02 1.01 0.97
TM8X100C20MP11 CF/CM/CU60D 1.02 1.02 0.97
TM8X100C20MP11 CF/CM64D 1.04 1.02 0.97
TM8X120C20MP11 CF/CM/CU48C 1.00 0.98 0.96
TM8X120C20MP11 CF/CM/CU48D 0.99 0.95 0.93
TM8X120C20MP11 CF/CM/CU60C 1.02 1.01 0.97
TM8X120C20MP11 CF/CM/CU60D 1.02 1.02 0.97
TM8X120C20MP11 CF/CM64D 1.04 1.02 0.97
TM8Y080C16MP11 CF/CM/CU48C 1.00 0.97 0.98
TM8Y080C16MP11 CF/CM/CU48D 1.00 0.98 0.98
TM8Y080C16MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8Y080C16MP11 CF/CM/CU60D 1.02 1.00 0.98
TM8Y080C16MP11 CF/CM64D 1.02 1.00 0.97
TM8Y100C16MP11 CF/CM/CU48C 1.00 0.97 0.98
TM8Y100C16MP11 CF/CM/CU48D 1.00 0.98 0.98
TM8Y100C16MP11 CF/CM/CU60C 1.01 0.99 0.97
TM8Y100C16MP11 CF/CM/CU60D 1.02 1.00 0.98
TM8Y100C16MP11 CF/CM64D 1.02 1.00 0.97
TM8Y100C20MP11 CF/CM/CU48C 1.00 0.98 0.96
TM8Y100C20MP11 CF/CM/CU48D 0.99 0.95 0.93
TM8Y100C20MP11 CF/CM/CU60C 1.02 1.01 0.97
TM8Y100C20MP11 CF/CM/CU60D 1.02 1.02 0.97
TM8Y100C20MP11 CF/CM64D 1.04 1.02 0.97
