Luxaire TC7B3621S - Page 7

5186767-LTG-B-0816
Johnson Controls Unitary Products 7
TC7B3621S AP48CX21 21.0 – 1175 36.0 26.0 14.75 12.75
TC7B3621S AP48DX21 24.5 – 1175 36.0 26.0 14.75 12.75
TC7B3621S AP60CX21 21.0 – 1350 36.0 27.0 14.25 12.25
TC7B3621S AP60DX21 24.5 – 1225 36.0 26.0 14.00 12.20
TC7B3621S AVC36BX21 17.5 – 975 34.6 23.6 16.25 13.75
TC7B3621S AVC36CX21 21.0 – 975 34.6 23.6 16.50 14.00
TC7B3621S AVC42CX21 21.0 – 1100 35.4 25.6 17.00 14.00
TC7B3621S AVC48CX21 21.0 – 1075 36.0 25.4 17.00 14.00
TC7B3621S AVC48DX21 24.5 – 1150 36.0 26.0 17.00 14.25
TC7B3621S AVC60CX21 21.0 – 1125 36.0 25.8 17.00 14.25
TC7B3621S ME12BN21 17.5 CF/CM36B 1025 34.6 24.0 16.20 13.75
TC7B3621S ME12BN21 17.5 CF42B 975 35.4 24.2 16.25 13.50
TC7B3621S ME14DN21 24.5 CF/CM36D 1250 34.6 26.2 16.50 14.00
TC7B3621S ME14DN21 24.5 CF/CM42D 1225 35.4 26.0 17.00 14.25
TC7B3621S ME14DN21 24.5 CF/CM48D 1200 36.0 26.6 17.00 14.25
TC7B3621S ME14DN21 24.5 CF/CM60D 1050 36.0 25.4 17.00 14.50
TC7B3621S ME16CN21 21.0 CF/CM36C 1250 34.6 26.0 16.50 14.00
TC7B3621S ME16CN21 21.0 CF/CM42C 1225 35.4 26.0 17.00 14.25
TC7B3621S ME16CN21 21.0 CF/CM48C 1250 36.0 26.8 17.00 14.25
TC7B3621S ME16CN21 21.0 CF/CM60C 1250 36.0 26.8 17.00 14.25
TC7B3621S ME20DN21 24.5 CF/CM36D 1325 35.4 27.2 15.50 13.25
TC7B3621S ME20DN21 24.5 CF/CM42D 1350 36.0 27.2 16.20 13.50
TC7B3621S ME20DN21 24.5 CF/CM48D 1350 36.0 27.4 16.25 13.75
TC7B3621S ME20DN21 24.5 CF/CM60D 1350 36.0 27.2 16.50 13.75
TC7B3621S MVC08BN21 17.5 CF/CM36B 1025 36.0 25.2 15.75 13.25
TC7B3621S MVC12BN21 17.5 CF/CM36B 1000 36.0 25.0 15.75 13.25
TC7B3621S MVC12BN21 17.5 CF42B 1025 36.0 25.0 16.00 13.25
TC7B3621S MVC14DN21 24.5 CF/CM36D 1175 36.0 26.4 16.50 13.75
TC7B3621S MVC14DN21 24.5 CF/CM42D 1125 36.0 26.0 17.00 14.00
TC7B3621S MVC14DN21 24.5 CF/CM48D 1125 36.0 26.0 17.00 14.00
TC7B3621S MVC14DN21 24.5 CF/CM60D 1075 36.0 25.4 17.00 14.00
TC7B3621S MVC16CN21 21.0 CF/CM36C 1125 36.0 26.2 16.00 13.50
TC7B3621S MVC16CN21 21.0 CF/CM42C 1025 36.0 25.2 16.50 13.75
TC7B3621S MVC16CN21 21.0 CF/CM48C 1075 36.0 25.6 17.00 14.00
TC7B3621S MVC16CN21 21.0 CF/CM60C 1175 36.0 26.4 17.00 14.00
TC7B3621S MVC20DN21 24.5 CF/CM36D 1150 36.0 26.4 16.50 14.00
TC7B3621S MVC20DN21 24.5 CF/CM42D 1200 36.0 26.4 16.50 13.75
TC7B3621S MVC20DN21 24.5 CF/CM48D 1100 36.0 26.0 17.00 14.00
TC7B3621S MVC20DN21 24.5 CF/CM60D 1175 36.0 26.6 17.00 14.25
TC7B4221S AE42CX21 21.0 – 1175 41.5 27.8 17.00 13.75
TC7B4221S AE48CX21 21.0 – 1225 42.0 28.4 17.00 14.25
TC7B4221S AE48DX21 24.5 – 1225 42.0 28.6 17.00 14.25
TC7B4221S AE60CX21 21.0 – 1425 42.0 30.6 17.00 14.00
TC7B4221S AE60DX21 24.5 – 1400 42.0 30.2 17.50 14.25
TC7B4221S AP42CX21 21.0 – 1225 40.5 27.2 15.00 12.50
TC7B4221S AP48CX21 21.0 – 1300 41.5 28.6 15.50 12.75
TC7B4221S AP48DX21 24.5 – 1350 42.0 29.2 15.50 13.00
TC7B4221S AP60CX21 21.0 – 1400 42.0 30.0 15.25 12.50
TC7B4221S AP60DX21 24.5 – 1400 42.0 30.0 15.25 12.50
TC7B4221S AVC42CX21 21.0 – 1175 41.5 27.8 17.00 13.75
TC7B4221S AVC48CX21 21.0 – 1225 42.0 28.4 17.00 14.00
TC7B4221S AVC48DX21 24.5 – 1225 42.0 28.6 17.00 14.25
TC7B4221S AVC60CX21 21.0 – 1275 42.0 29.4 17.00 14.00
Continued on next page.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
