5186767-LTG-B-0816
Johnson Controls Unitary Products 71
COIL MULTIPLIERS- 5 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU60C 0.98 1.00 1.04
– CF/CM/CU60D 0.98 1.00 1.04
– CF/CM64D 1.00 1.00 1.00
AE60CX21 – 0.97 0.97 0.99
AE60DX21 – 1.01 1.01 1.01
AP60CX21 – 0.97 0.94 1.05
AP60DX21 – 0.97 0.97 1.03
AVC60CX21 – 0.98 0.99 1.02
AVC60DX21 – 1.01 1.00 0.99
ME16CN21 CF/CM60C 0.99 1.02 0.99
ME20DN21 CF/CM60D 0.98 0.97 0.98
ME20DN21 CF/CM64D 1.01 0.99 0.99
MVC16CN21 CF/CM60C 0.97 0.97 0.99
MVC20DN21 CF/CM60D 0.98 0.98 0.98
MVC20DN21 CF/CM64D 0.99 0.99 0.97
FURNACE MULTIPLIERS- 5 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP11 CF/CM64D 0.99 0.98 1.01
TM8V100C16MP11 CF/CM64D 0.99 0.98 1.01
TM8V100C20MP11 CF/CM/CU60D 0.97 0.98 1.03
TM8V120C20MP11 CF/CM/CU60D 0.97 0.98 1.03
TM8X100C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TM8X100C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TM8X100C20MP11 CF/CM64D 1.00 0.99 1.00
TM8X120C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TM8X120C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TM8X120C20MP11 CF/CM64D 1.00 0.99 1.00
TM8Y100C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TM8Y100C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TM8Y100C20MP11 CF/CM64D 1.00 0.99 1.00
TM8Y120C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TM8Y120C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TM8Y120C20MP11 CF/CM64D 1.00 0.99 1.00
TM9E100C20MP11 CF/CM/CU60D 0.97 0.97 1.01
TM9E120D20MP11 CF/CM/CU60D 0.97 0.97 0.99
TM9V080C16MP11 CF/CM/CU60C 0.97 0.95 1.03
TM9V080C16MP11 CF/CM64D 1.00 0.98 1.02
TM9V100C16MP11 CF/CM/CU60C 0.97 0.95 1.03
TM9V100C16MP11 CF/CM64D 1.00 0.98 1.02
TM9V100C20MP11 CF/CM64D 0.99 0.98 1.01
TM9V120D20MP11 CF/CM/CU60D 0.99 1.03 1.03
TM9V120D20MP11 CF/CM64D 1.01 1.01 1.03
TM9Y100C20MP11 CF/CM/CU60D 0.97 0.97 1.01
TM9Y120D20MP11 CF/CM/CU60D 0.97 0.97 0.99
TMLV080C16MP11 CF/CM64D 0.99 0.98 1.01
TMLV100C16MP11 CF/CM64D 0.99 0.98 1.01
TMLV100C20MP11 CF/CM/CU60D 0.97 0.98 1.03
TMLV120C20MP11 CF/CM/CU60D 0.97 0.98 1.03
TMLX100C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TMLX100C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TMLX100C20MP11 CF/CM64D 1.00 0.99 1.00
TMLX120C20MP11 CF/CM/CU60C 0.97 0.97 1.01
TMLX120C20MP11 CF/CM/CU60D 0.97 0.97 0.99
TMLX120C20MP11 CF/CM64D 1.00 0.99 1.00
TP9C080C16MP12 CF/CM/CU60C 0.97 0.95 1.03
TP9C080C16MP12 CF/CM64D 1.00 0.98 1.02
TP9C100C16MP12 CF/CM/CU60C 0.97 0.95 1.03
TP9C100C16MP12 CF/CM64D 1.00 0.98 1.02
TP9C100C20MP12 CF/CM64D 0.99 0.98 1.01
TP9C120D20MP12 CF/CM/CU60D 0.99 1.03 1.03
TP9C120D20MP12 CF/CM64D 1.01 1.01 1.03
TPLC080C16MP12 CF/CM64D 0.99 0.98 1.01
TPLC100C16MP12 CF/CM64D 0.99 0.98 1.01
TPLC100C20MP12 CF/CM/CU60D 0.97 0.98 1.03
TPLC120C20MP12 CF/CM/CU60D 0.97 0.98 1.03
LP9C080C16MP12 CF/CM/CU60C 0.97 0.95 1.03
LP9C080C16MP12 CF/CM64D 1.00 0.98 1.02
LP9C100C16MP12 CF/CM/CU60C 0.97 0.95 1.03
LP9C100C16MP12 CF/CM64D 1.00 0.98 1.02
LP9C100C20MP12 CF/CM64D 0.99 0.98 1.01
LP9C120D20MP12 CF/CM/CU60D 0.99 1.03 1.03
LP9C120D20MP12 CF/CM64D 1.01 1.01 1.03
LPLC080C16MP12 CF/CM64D 0.99 0.98 1.01
LPLC100C16MP12 CF/CM64D 0.99 0.98 1.01
LPLC100C20MP12 CF/CM/CU60D 0.97 0.98 1.03
LPLC120C20MP12 CF/CM/CU60D 0.97 0.98 1.03
FURNACE MULTIPLIERS- 5 TON (Continued)
Furnaces Coil T.C. S.C. KW
