LX Era
Device setup
Document name: LX EUM
Document revision: R1
5.1.7.1 Airspace
The airspace sub-menu holds the settings for colour and transparency of the fill and outline for
the following airspace types:
• Controlled zone
• Prohibited
• Restricted
• Danger
• Terminal area
• Airway
• Glider
• Military
• Other
• Class A, B
• Class C
• Class D
• Class E
• Class F
5.1.7.2 Map
The Map sub-menu holds settings for the graphical appearance of the Map are on all navigation
pages. The following settings are available.
• Orientation - offers the two common map orientations - ’North up’ and ’Track up’.
• TP/APT text size - changes the size of airports and turnpoints names on the map.
• Dest. line colour - the colour of the line connecting your current position and your navi-
gation point.
• Track line colour - the colour of the line showing your current true track.
• Display APT names - whether or not to display airport names (alongisde the icon) on the
map.
• Display TP names - whether or not to display turnpoint names (alongside the icon) on the
map.
NOTE
APT icons are shown on the map up to a zoom level of 25km. TP icons are shown
up to a zoom level of 9km. At higher zoom levels we are only showing Airspace
lines, due to the legibility.
5.1.7.3 Task
The Task sub-menu holds settings for the graphical appearance of task features on the task
navigation page map. The following settings are available.
• Active zones - outline, fill and start/finish line.
• Inactive zones - outline, fill and start/finish line.
• Task legs
– Legs yet to cover
– Active leg
– Course to TP
– Covered leg
Device manual Public 58
