Document revision: R1
5.2.3 NMEA
The NMEA sub-menu is used for determining which sentences are being sent out through the
User port, Flarm port and the Bluetooth connection. This sub-menu will only explain in small
detail what is available and what it is used for. For more information on connectivity, check the
Connectivity section.
The following settings are available:
• Flarm - sets the baudrate for the Flarm port. Default value is 19200.
• User - sets the baudrate fot the User port. Default value is 38400.
• GPGGA - forwards GPGGA (Fix information) sentences received from GNSS module.
• GPRMC - forwards GPRMC (Recommended minimum data for gps) sentences received
from GNSS module.
• GPRMB - outputs Recommended minimum navigation info.
• LXWPx - outputs LXWP0 (flight data), LXWP1 (device info), LXWP2 (basic parameters),
LXWP3 (detailed parameters) sentences.
• LXDT - enables LXDT (data transfer) communication (input and output)
• LXBC - outputs LXBC (broadcast) sentences (AHRS data, etc.)
• PFLAx - Flarm sentences, includes ”PFLAU”, ”PFLAA”, ”PFLAC”, ”PFLAE”, ”PFL AL”,
”PFLAQ”. For individual sentence specification check Flarm documentation.
• Levil - reserved for use with Levil devices.
• Radio - when Radio option is enabled - ”On”, all other outputs on ”User” port are disabled,
but are still present via ”Bluetooth” port. The following radio transcievers are available:
– KRT2
– ATR833
– Becker
– Trig
– AIR avionics
• Send APT freq - confirms whether or not you wish the Era to send the frequency of the
selected airport on Airport navigation page to the Radio.
• Transponder - if enabled - ”On”, baudrate on ”Flarm” port will go to ”BR9600” and GPS
data will be transmitted on ”Flarm” port.
NOTE
In normal use, it is recommended that the GPGGA, GPRMC, GPRMB, LXWPx,
LXDT, LXBC and PFLAx sentences are checked, unless explicitly noted otherwise.
NOTE
For detailed description of LXWPx, LXDT and LXBC sentences refer to LX
Navigation Data Port documentation (document name: LX CP).
Device manual Public 65
