Lynx L15ICE - Installation Space Requirements

Lynx L15ICE 8
Installaon Instrucons
L15ICE
Installation Space
Model Height Width Depth
L15ICE 34” (864mm) 15” (381mm) min. 24” (610mm)min.
IMPORTANT: Remove the doors from your old ice machine.
1. Do not let the weight of the counter rest on the icemaker.
2. Do not build in the icemaker in a corner where the door will hit other equipment such as an oven handle or where
the icemaker cannot be pulled out for service.
