7
CARE AND USE/INSTALLATION
INSTALLING THE DRAIN PLUMBING
This drain pump is designed to be installed in Lynx ice
machines only and approved for use with water only.
!
CAUTION
Figure 10
Drain pump
vent tube.
Keep this
open to
assure air
ows freely
as water
enters
the pump
reservoir.
Drain line coiled and
secured to the back of the
cabinet. Uncoil, route to
an appropriate drain and
cut to length.
Optional Drain Pump.
An optional drain pump is available if you have purchased
an ice machine without one and do not have access to a
gravity drain. Installation instructions are provided with the
optional drain pump. Contact Lynx Grills Customer Service
at 888.289.5969 or your dealer for ordering.
Electrical Shock Hazard
Risk of electrical shock or personal injury could occur
due to moving components, if the machine compartment
access cover is removed before unplugging the ice
machine power cord.
!
WARNING
