WIRING DIAGRAM (FIELD)
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF NAPOLEON/LYNX. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF NAPOLEON/LYNX IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
PHOTO EYES
RX
TX
3-BUTTON STATION
OPEN
STOP
CLOSE
3-BUTTON STATION
OPEN
STOP
CLOSE
3-BUTTON STATION
OPEN
STOP
CLOSE
OPEN
CLOSE
STOP
COM
WIRING FOR MULTIPLE 3 BUTTON STATIONS
3-BUTTON STATION
OPEN
STOP
CLOSE
MA
STOP
CLOSE
BEAMS
OPEN
OPEN
STOP
CLOSE
EDGE
COM
SINGLE
COM
LEARN
TTC PROGRAM
*IF USING COAXIAL ANTENNA CUT PROVIDED ANTENNA NEAR CIRCUIT BOARD
NOT POLARITY SENSITIVE
NORMALLY OPEN
SAFETY DEVICE
(OPTIONAL)
MOMENTARY
SWITCH
INTERLOCK
(WHEN NEEDED)
**
Rev. 09/11/15
LX-900 Wiring Connections
*COAXIAL ANTENNA CONNECTION
**Stop and Com must be jumpered when a 3-Button Wall Station is not Present
LDT, LDTB16
