Appendices
Appendix A - Technical Specifications
Type: Two-way desktop reference speaker
Low-frequency driver: 3" Diameter, polypropylene-coated, magnetically shielded with
high-temperature voice coil
High-frequency driver: 1" Diameter, magnetically shielded silk cone tweeter
Frequency response: 90 Hz – 20 kHz
Crossover frequency: 3.3 kHz
RMS SPL: 101.5 dB @ 1 meter
Signal-to-noise ratio: > 90 dB (typical, A-weighted)
Input connectors: Left and right RCA line input and 1/8" aux input
Polarity: Positive signal at "+" input produces outwardlow-frequency cone
displacement
Dynamic power: 10 Watts continuous, per channel into 4 Ω
Input impedance: 10 k Ω unbalanced, 20 k Ω balanced
Input sensitivity: 100 mV pink noise input produces 90 dBA output SPL at 1 meter
with volume control at maximum
Protection: RF interference, output current limiting, over temperature, turn on/
off transient, subsonic filter
Indicator: Blue power LED ring around volume knob on front panel
Power requirements: 100-120V/~50/60 Hz, 220-240V/~50/60 Hz; powered via
detachable 2-conductor line cord
Cabinet: Vinyl-laminated MDF
Dimensions: 7.9" (H) x 5.3" (W) x 6.3" (D) 20 cm (H) x 13.4 cm (W) x 16 cm (D)
Weight: 11.7 lbs. / 5.3 kg
Specifications subject to change without notice
