7
Specifications
General
Maximum Input - Mic In: -25 dBv
Maximum Input - Instr. In: -5 dBv
Maximum Output - Balanced: 24 dBv
Maximum Output - Unbalanced: 10 dBv
Headroom: 20 dB
Maximum Gain - Mic In: 70 dB
Maximum Gain - Instr. In: 50 dB
Clip Indicator: 2 dB below threshold of clipping
Low Cut Filter Cutoff: 3 dB down @ 72 Hz
Low Cut Filter Slope: 18 dB/Octave
Input Impedance (1 kHz) - Mic In: 3 kOhms
Input Impedance (1 kHz) - Instr. In: 100 kOhms
Mic Input/ Guitar Input/
Balanced Output Unbalanced Output
THD (20 Hz - 20 kHz) < 0.0065% < 0.0015%
S/N (20 Hz - 20 kHz) > 85 dB > 99 dB
Frequency Response
31.5 Hz - 80 kHz/31.5 Hz - 25 kHz +/- 0.1 dB +/- 0.1 dB
9.5 Hz -2.5 dB -0.75 dB
120 kHz -1 dB -5 dB
Weight: Under l lb.
Power Supply: 9vAC 500mA supply w/2.5mm plug.
Output Impedance: 500 Ohms.
