Parts List
+++++ 628071217 Flat connector with cathode plug
3Pin L=60mm 26# UL2468 Red 3Pin/2.54mm
cathode plug
1.00000 PCS JP3
+++++ 901010013 Stannum of cord sotder wire (lead) Sn-0.3Ag-0.7Cuφ1.0mm FLUX;2.2% 0.00220 ROLL
+++ 631020017 Black Velvet paper 66*30*0.3mm viscosity 5.00000 PCS
+++ 301110029 screw BB 4*12BB(00683-54012) black “+” PWB 16.00000 PCS
+++ 628072314 Flat connector with cathode plug
20芯 L=575mm 10PIN*2/2.54
1.00000 PCS
+++ 628072313 Flat connector with cathode plug 20 PIN L=835 10PIN*2/2.54 1.00000 PCS
+++ 1010118430 Main board ASSY KS88 MK3(MK35B) MAIN BOARD 1.00000 SET
++++ 6210200410 Slide Switch 2 Position HSK22F03G7 350gf-036 HongYu 1.00000 PCS SW1
++++ 628010400 Masculine Connector 2*10P/2.0 180° DIP 1.00000 PCS J10
++++ 628010293 Masculine connector
6Pins/2.00mm pitch single line straight prevent
fall off
1.00000 PCS J1
++++ 620010006 DC JACK 3Pin DS-210 DIP 1.00000 PCS DJ1
++++ 620020047 Stereo jack 4PIN ST-015 PBT DIP The pore size of 6.5mm 2.00000 PCS J6 J9
++++ 620030003 MIDI JACK 7PIN DIN-01R-M10 DIP 1.00000 PCS J4
++++ 620050025 USB JACK
ST-001B-02 P=2.0mm Mating and Unmating
Foce:15N~30N Black Plastic
1.00000 PCS J3
++++ 628010084 Masculine connector
10PIN*2 straight feet DUAL ROW WITH BOX
HEADER
2.00000 PCS CN1-2
++++ 604990016 Common mode choke
30uH T6*3*2-0.25*8TS V9.5*8.5*10mm
W6.5*5mm
1.00000 PCS FB10
++++ 1010118420 Main board ASSY(AI part) KS88 MK3(MK35B) 1.00000 SET
+++++ 60308001102
CAP ELECT DIP with Tape&Reel
Packing
100uf/16V +20% -20% 5*11mm Pitch:2.5MM 4.00000 PCS C13-14 C56 C58
+++++ 60308006702
CAP ELECT DIP with Tape&Reel
Packing
470uf/16V +20% -20% 8*12mm DIP Pitch:2.5MM 3.00000 PCS C47 C11 C52
+++++ 60308005802
CAP ELECT DIP with Tape&Reel
Packing
47uf/25V +20% -20% 5*11mm Pitch:2.5MM 6.00000 PCS C3 C7 C15 C53 C68 C70
+++++ 1010118410 Main board ASSY(SMD part) KS88 MK3(MK35B 1.00000 SET
++++++ 603010157 CAP CERAMIC SMD 100pf/50V +10%-10% 0402 SMD 30.30000 PCS C18-45 C62 C64
++++++ 603010231 CAP CERAMIC SMD 0.1uf/50V +10%-10% 0402 X7R 14.14000 PCS
C1-2 C4-6 C8 C12 C16-17
C61 C63 C66-67 C78
++++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 9.09000 PCS
C46 C48 C65 C54-55 C69
C71-72 C60
++++++ 603010270 Ceramic CAP SMD 20P/50V +/- 2% 0402 NPO Yageo 2.02000 PCS C9-10
++++++ 603010155 CAP CERAMIC SMD 47pf/50V +10%-10% 0402 SMD 2.02000 PCS C79-80
++++++ 603010272 CAP SMD 510pf/50V +5% -5% 0402(NP0) SMD 2.02000 PCS C49-51
++++++ 603010004 CAP CERAMIC SMD 100pf/50V +5% -5% 0603(NP0) SMD 2.02000 PCS C57 C59
++++++ 506040673 PCB Dual layer FR4 1.6mm 143.6X86X1.6MM MK35B_MB_V01) 1.00000 PCS
++++++ 608090008 ESD SUPPRESSOR TESC0R15V05B1X 5V/0.15PF 0603 9.09000 PCS D5-7 D11 D13-17
++++++ 606010035 Ferrite Bead SMD BLM18PG471SN1D 1A 0603 murata 4.04000 PCS FB1-2 FB4 L1
++++++ 606010012 Ferrite Bead SMD 500mA 600 OHM@100MHz 0805 3.03000 PCS FB3 FB5-6
++++++ 6060100200 Ferrite Bead SMD BLM18BD102SN1D 1000ohm 0.1A 0603 9.09000 PCS L3-5 L7-11 L13
++++++ 6060100400 Ferrite Bead SMD
BLM15AG102SN1D Ferrite Chip Bead
1kOhm@100MHz 300mA 0402 Murata
38.38000 PCS
L14-20 L21 L22-30 L31 L41
L51 L32-40 L42-50
++++++ 6049900040 Common mode inductor
280mA COMMON MODE 0805 ROHS“MURATA”
DLW21HN121SQ2 SMD
1.01000 PCS L6
++++++ 608030002 Rectifier Diode SMD IN4001 6.00*3.00mm 1.00500 PCS D3
++++++ 608010034 Switch Diode SMD 1N4148W SOD-123FL 3.01500 PCS D1 D9-10
++++++ 608040002 Schotthy Diode SMD SS24 2A 40V 2.01000 PCS D2 D4
++++++ 6010109330 IC SMD
AMS1117-3.3 SOT-223 linear regulater 3.3V 1A
AMS
1.00000 PCS U3
++++++ 6010105280 IC SMD BA17805FP 3feet 1.00000 PCS U4
++++++ 602010645 Resistor SMD 0 ohm(1/16w)+1%-1% 0402 1.01000 PCS R7
++++++ 602010001 Resistor SMD 0 ohm(1/16w)+1%-1% 0603 1.01000 PCS R8
++++++ 602010009 Resistor SMD 100 ohm(1/16w)+1%-1% 0603 1.01000 PCS R15
++++++ 602010644 Resistor SMD 100 ohm(1/16w)+1%-1% 0402 1.01000 PCS R22
++++++ 602010806 Resistor SMD 10K ohm(1/16w)+0.1%-0.1% 0402 1.01000 PCS R10
++++++ 602010393 Resistor SMD 10K ohm(1/10w)+1%-1% 0603 4.04000 PCS R4 R9 R13 R25
++++++ 602010731 Resistor SMD 1M ohm(1/16w)+1%-1% 0402 Yageo 3.03000 PCS R1 R26 R28
++++++ 602010763 Resistor SMD 27 ohm(1/16w)+1%-1% 0402 Yageo 2.02000 PCS R16 R17
++++++ 602010713 Resistor SMD 33 ohm(1/16W)+1%-1% 0402 Yageo 1.01000 PCS R2
++++++ 602010145 Resistor SMD 4.7K ohm(1/8w)+5%-5% 0603 11.11000 PCS
R6 R14 R18-21 R23-24 R27
R29-30
++++++ 602010205 Resistor SMD 68 ohm(1/8w)+5%-5% 0603 2.02000 PCS R5 R11
++++++ 602030020 Resistor chain SMD 4.7K ohm(1/16w)+5%-5% CRN164 4.02000 PCS AR1-2 AR4 AR6
++++++ 609010074 Transistor SMD SS8050 NPN SOT-23 1.00500 PCS Q1
++++++ 609010053 Transistor SMD MMBT8550D(1500mA) PNP SOT-23 1.00500 PCS Q2
