9
4. MOD Wheel: Move this wheel to send continuous controller data—MIDI CC #01 (modulation), by
default.
5. DAW / PRESET [EDIT] Button: Press this button to set Oxygen Pro Mini to operate in
DAW Mode or Preset Mode. When in DAW Mode, this button’s LED will be brightly lit. When in
Preset Mode, this button’s LED will be off. Hold Shift and press this button to edit a Preset or
User DAW. After editing the Preset or User DAW, press this button again to save your changes to
the User DAW or Preset. Press and hold the button to open the DAW/Preset Select menu on the
Display.
6. Display: The main Display screen shows the status of the last used control. Use this screen to
monitor parameter levels as you adjust controls on the keyboard. Also, use the Display along
with the Select/Scroll Encoder to view and edit keyboard settings.
7. Select/Scroll Encoder: If you are entered into one of the Display’s Edit menus, turn this knob to
change settings/parameters and press the knob to confirm a selection.
If you are not viewing any of the edit menus, turning the encoder and pressing the encoder will
each function as separate MIDI controls. When operating with a DAW, the assigned controls will
be predetermined. When operating with a preset or the User DAW selected, the controls can be
edited.
8. BACK Button: If you have entered into one of the Display’s Edit menus, press this button to go
back to the main Display screen.
If you are not viewing one of the Edit menus, this button will be assigned to a control. When
operating with a DAW, the assigned control will be predetermined. When operating with a preset
or the User DAW selected, the control can be edited.
When editing a Preset or DAW name press the Shift button and the Back button to delete a
letter.
