M-Audio OXYGEN PRO MINI Quick Start Guide

8
Basic Operation
Top Panel
Important: Visit m-audio.com to download the complete User Guide.
1. Keybed: Using the Octave buttons, you can access the full 88-note keyboard range of a large
piano keyboard. The Oxygen Pro Mini keybed has 2 1/2 playable octaves. The range of the
keyboard is approximately in the middle of an 88-note keyboard.
2. OCTAVE +/-: The assignable octave buttons are used to shift the keyboard up or down in one-
octave increments (12 semitones at a time). This extends the range of the keyboard up to four
octaves in either direction, which lets you play notes that lie outside of the 32 keys. Hold Shift
and press these buttons to adjust the pitch range of the keys up or down one semitone. To return
the octave shift to 0, press both the Octave buttons together.
3. PITCH Wheel: Roll this wheel up and down from the center position to bend the pitch of the
keyboard while playing. The default range of the pitch-bend will vary between software synths.
The wheel is spring mounted and will return to the center position when released.
1
2
3
4
5
6
7
8
9
12
13 14
17
18
19
21
22
23
25
20
11
10
15
24
26
27
16

M-Audio OXYGEN PRO MINI Specifications

General

Control type	Buttons, Rotary, Slider
Number of pads	8
MIDI-keyboard number of keys	32 keys
Product color	Black
Octave adjustment	Yes
Display type	OLED
Power source type	USB

Weight and Dimensions

Depth	190 mm
Width	401 mm
Height	60 mm
Weight	1200 g
