27
LED Parameters
Parameters LED
Type - Up Up
Type - Down dn
Type - Incl inc
Type - Excl Ecl
Type - Order ord
Type - Random rnd
Type - Chord crd
Gate - 0 0
Gate - 10 10
Gate - 20 20
Gate - 30 30
Gate - 40 40
Gate - 50 50
Gate - 60 60
Gate - 70 70
Gate - 80 80
Gate - 90 90
Gate - 100 100
Swing - 50 50
Swing - 55 55
Swing - 57 57
Swing - 59 59
Swing - 61 61
Swing - 64 64
Swing - 66 66
Swing - 75 75
Octave - 0 0
Octave - 1 1
Octave - 2 2
Smart Chord Control
On the Oxygen, when SHIFT and either the < or > button is pressed, it will enable you to select and
activate the keyboard’s internal Smart Chord Mode. When Smart Chord is active, the Chord LED will
be lit. The Smart Chord settings are based on the current Key, Voicing, and Type settings. Key,
Voicing, and Type settings are editable when Smart Chord mode is active and using the SHIFT
button and pressing one of the Key, Voicing, or Type keys.
When Smart Chord mode is active a single key press will play a chord as selected in the current
Smart Chord Edit options. This functionality is available in the 2 keyboard modes, DAW, PRESET.
You can turn on and off Smart Chord Mode by pressing both < and > buttons simulationously.
• Smart Mode: In this Mode, you will first assign the keyboard to a musical key (e.g. D minor).
Then you will assign the desired voicing for the chords (what intervals will be included in the
chord, e.g. 1-3-5). Each key’s chord voicing will then be automatically enharmonic to the
selected key.
• Custom: In this Mode, you can determine the chord structure that will be assigned to each key
by manually playing it. For example, if you hold Shift and press the Custom key, the LED
display wil show “C5t”. When “C5t” is shown on the LED display, the Shift button can then be
released and you can press up to 6 keys simultaneously to enter in a custom chord, for
example 1-b3-5-b7 chord, every key will then be assigned to play this chord structure. The
note of the key you press will serve as the root of the chord.
