30
DAW Knob Control
Using the SHIFT button and Pads 9-12 (on the 25-key), or 9-11 (on the 49-key and 61-key)
will enable you to change the function of knobs in DAW mode.
DAW Mode
• Volume: Will change the knobs function to control the channel faders in your DAW.
• Pan: Will change the knobs function to control the channel pan knobs in your DAW.
• Device: Will change the knobs function to control the currently selected channel’s plugin
controls in your DAW.
Note: Not all DAWs support Device control.
• Sends: Will change the knobs function to control the currently selected channel’s send
controls in your DAW.
Note: Not all DAWs support Sends control.
Channel Selection
This selects the MIDI channel that will be used to send MIDI messages from the keys, pads,
knobs, faders, and buttons.
The last selected control will be the one selected for editing. For example, if the keys are
pressed before pressing Shift Button and the Channel key are pressed, then the keybed’s
channel will be selected for editing.
Value LED
G,1-16 G1o, 1-16
Velocity Curve
The Velocity Curve selects the velocity curve that the keyboard or drum pads will use for each
MIDI note. There are 4 different velocity curve settings, and 3 fixed dettings. The 4 velocity
curve settings are Low, Medium, High, and Linear. The 3 fixed velocity settings give velocities
of 64, 100, and 127, respectively.
The last selected control will be the one selected for editing. For example, if the keys are
pressed before pressing Shift Button and the Velocity key are pressed, then the keybed’s
velocity curve will be selected for editing.
If the Velocity Curve function is selected for the drum pads, all drum pads will begin flashing to
show their Velocity is being edited.
As Velocity Curves are selected, the LED Display will show the curve in the format as listed
above.
Performance Mode will resume after 2 seconds of a value being selected.
