3 CR10-10001 Resistor, Metal Film, 1/16W, 1%, 100, 0603 A 2 R10,R17
3 CR10-10021 Resistor, Metal Film, 1/16W, 1%, 10K, 0603 A 1 C1
3 CR10-75011 Resistor, Metal Film, 1/16W, 1%, 7.5K, 0603 8 R2-R9
3 CX01-00009 Crystal, 12 MHz, 100PPM, 32pF, Fundamental,
HC-49/US
A1 Y2
3 EC04-00010 Connector, Header, 1x10, 2mm, Male,
C10110P1VK0, Vert, Shrd
A 2 J1,J8
3 EC04-00016 Connector, Header, 1x2, 2.54mm, Male, 22-28-
4020, Vert.
1J6
3 EC04-00102 Connector, Header, 1x8, 2.54mm,
Female/RECP, 535541-6, Vert
1J4
3 EC04-00103 Connector, Header, 1x14, 2.54mm, Female, 1-
535541-2, Vert
1J7
3 IM12-23540 IMAGE, FILE, S0-49, VELOCITY, MCU, 8K
FLASH, BIN
B1
3 PI12-23540 PROGRAMMED,IC, S0-49, MCU, FLASH,
ARM7, LPC2101FBD48
B1 U6
4 CJ11-00145 IC, MCU, ARM7, 16/32-Bit, LPC2101FBD48,
8K Flash, 2K SRAM, LQFP-48
1U6
4 IM12-23540 IMAGE, FILE, S0-49, VELOCITY, MCU, 8K
FLASH, BIN
B1
3 XX00-00008_V2 XX00-00008, DNP (XJ3), S0-49 0
2 9310-61788-00 LBL,INDIVIDUAL UNIT C 1
3 9470-61787-00 DOC CM,PRODUCT LABELING
REQUIREMENTS
D1
2 9490-65062-00 ASY,MFG DOCS,9100-65005-00,VENOM
SYNTH
C1
3 9158-65024-00 MFG TEST PROC,S0-49 USER GUIDE C 1
3 9163-65027-00 PID,9100-65005-00,VENOM SYNTH=DCJ A 1
3 9164-65012-00 MFG TEST SW,S0-49 C 1
2 AA02-235
Assy, Mechanical, Parts List, S0-49
A1
3 2403-65004-00 KYPD,S0-49,KEYBED A 1
3 2501-65002-00 JOG,WHL,S0-49,PIT A 1
3 2501-65003-00 JOG,WHL,S0-49,MOD A 1
3 9150-65015-00 ASY,PCB,S0-49,LCD A 1
3 MM02-00100 Mech, Panel, Painted and silk-screened, S0-49
top cabinet
11
4 MM02-00100X MM02-00100x, unpainted part, S0-49 1
4 PS00-00002 SILKSCREEN AND COLOR SPECS,
ARTWORK, S0-49
71
3 MM02-00101 Mech, Panel, Painted and silk-screened, S0-49
bottom cabinet
11
4 MM02-00101X MM02-00101x, unpainted part, S0-49 1
4 PS00-00002 SILKSCREEN AND COLOR SPECS,
ARTWORK, S0-49
71
2 AB12-235
ASSY, PCB, S0-49, MAIN
G1 1
3 CB12-235 PCB, SO-49, MAIN G 1
To Next Page
