#BOMfor9900‐52873‐00:VENOMSYNTHESIZERUS
Level Part Number Description Rev Qty Ref Des
1 4000-65002-00 PWR SPLY,9V DC,1 AMP,US A 1
1 6501-65008-00 BAG,PLASTIC,S0-49 UNIT A 1
1 6501-65010-00 BAG,PLSTC,POLY 170 X 160 X 0.04 MM A 1
1 8410-02359-01 2
1 8420-01742-01 PACK KEYBOARD GIFTBOX HANDLE A 1
1 9100-65005-00 ASY,FNL,E/M UNIT,S0-49 H 1
2 9150-65016-00
ASY,PCB,S0-49,HEADPHONE
D0 1
3 CB42-235 PCB, S0-49 HEADPHONE BOARD D0 1
3 CC03-10031 Capacitor, Ceramic X7R, 25V, 100nF, 10%,
0603
2 C44,C48
3 CC13-10011 Capacitor, Ceramic NPO, 5%, 50V, 1nF, 0603 A 2 C38,C50
3 CC20-10053 Capacitor, Electrolytic, 16V, 10uF, 20%,
4x7x1.5mm
2 C42-C43
3 CJ01-45561 IC, Op Amp, NJM4556AM, Dual, High Current,
DMP-8/SO-8
1 U10
3 CR10-10011 Resistor, Metal Film, 1/16W, 1%, 1K, 0603 A 4 R61,R83-R85
3 CR10-10021 Resistor, Metal Film, 1/16W, 1%, 10K, 0603 A 6 R25-
R26,R52,R55,R159-
3 CR12-33R01 Resistor, Metal Film, 1/8W, 1%, 33, 1206 2 R51,R158
3 EC01-00002 Connector, PCB, 6.3mm Stereo Jack, Metal
Ring, with nut/washer, RT ANG
1 J21
3 EC04-00040 Connector, Header, 1x6, 2.54mm, Male, Vert,
SHRD
1 J16
2 9150-65017-00
ASY,PCB,S0-49,VELOCITY
A3 1
3 CB32-235 PCB, SO-49 VELOCITY BOARD A0 1
3 CC04-01041 CAPACITOR, CERAMIC X7R, 50V, 100NF,
10%, 0603
A 6 C34-C37,C100-C101
3 CC13-22C01 Capacitor, Ceramic NPO, 5%, 50V, 22pF, 0603 2 C8-C9
3 CC18-47051 Capacitor, Electrolytic, 6.3V, 47uF, 20%,
4x7x1.5mm
4 C2,C4,C7,C10
3 CD03-00008 Diode, Schottky, BAT54S, Dual, Series, 30V,
200mA, SOT-23
A1 D1
3 CJ03-11175 IC, Regulator, AP1117E18, +1.8V, LDO, 1A,
SOT-223
1U5
3 CJ11-00145 IC, MCU, ARM7, 16/32-Bit, LPC2101FBD48,
8K Flash, 2K SRAM, LQFP-48
1U6
3 CJ12-00006 IC, Logic 3.3V, 74LVC138AD,
Decoder/demultiplexer, 3-to-8, SO-16
2 U20-U21
3 CR02-00001 Resistor, Carbon Film, 1/16W, 5%, 0, 0603 1 R40
3 CR02-10021 Resistor, Carbon Film, 1/16W, 5%, 10K, 0603 A 9 27,R1,R11-
R13,R18,R36-R38
