The electronic control array for the oven system consists of:
Control, key panel, oven sensor, assembly for the door lacth and convection fan.
KEY PANEL TEST
1. Touch each pad on the Key Panel.
2. If the Key Panel is functioning properly, the following should occur:
• Bake, Broil, Convection Bake, Convection Roast, Clean, Timer, Clock, Stop Time and Cook
Time Modes – An audible tone sounds and the display shows the mode of the operation selected.
• Clear/Off – An audible tone sounds and the display shows the time of day.
• Number pads can only be used after another function has been selected.
To display fault codes in the memory simultaneously press and hold COOKING TIME and DELAY
START pads and then press number 9 pad..
